Page 118 - PECatalog_2015.pdf

POWER PARALLEL BARS

Econo-Line™ Power Height Parallel Bars
– 10’ long hardwood platform with tapered ends.
– Motorized height adjustment and manual width adjustment.
– Width Between Uprights is 26.5”
– Tapered EWDS for wheelchair accessibility.
010221
Length Width Height
010221 10’ 15”-28” 27”-42”
Clinical
Equipment
Electric Height Adjustable Parallel Bars
– Brackets included to lower rails to child height
– Includes manual override crank and removable abduction board.
– 010218(not shown) is 15’ long with (6) uprights.
– 110V, 60Hz and 3 Amps.
– Styrene-coated tapered wood base provides long wearing, secure footing for easy
usage.
010217
Length Width Height Electric height adjusts 27” to 37” for adults
010217 10’ 15”-27” 27”-37” and 17” to 27” for children and
010218 15’ 15”-27” 27”-37” width adjusts manually from 15” to 27”

Electric Height And Width Adjustable Parallel Bars
– Base wedges are tapered to accommodate wheelchairs.
– Handrails adjusts electrically for height from 27” to 37” and width from 13” to 25”.
– Width between uprights is 25”
– Includes manual override crank and removable abduction board.
– 010216 (not shown) is 15’ long with six uprights.
– 110V, 60Hz, 3 Amps.
Length Width Height
010215 10’ 13”-25” 27”-37”
010216 15’ 13”-25” 27”-37”

Mobility Platform (With Electric Height Bars) 010215
– Motorized height adjustment from 29” to 44” high. Handrails adjusts electrically for height from 27” to 37” and width from 13” to 25”
– (4) Direct drive synchronized lifting columns Styrene-coated, tapered maple bases provide taut, long wearing, secure footing for easy usage.
– Control Panel located near entry end of bars.
– Push button controls and digital bar height readout.
– Width adjusts manually from 15” to 28” wide with easy to use control knobs..
– Width between uprights is 26 1/2”
– 10’ Satin nish hardwood platform with recessed grommeted holes on surface.
– Balance Beam is 6’5”L x 6”W x 3”H and is equipped with anti-slip surface and dowel
pins.
– Tapered ends with anti-slip tread for easy wheelchair access.
– 110V, 60Hz, 2.5 Amps.
– 400lb weight capacity.
Length Width Height
010236 10’ 15”-28” 29”-42”

010236
Placement Ladder consists of (11) variably placed ladder steps. Each ladder
step has dowel pins, which t into grommeted holes of platform. The spacing
and location of ladder steps can easily be adjusted for patient’s gait training.

116 | This is a representation of the products we oer. If you don’t nd what you need on these pages please ask us about it.
