PARAMOUNT OFFICE PARTITIONS
®
WITH MODULAR WIRE
MANAGEMENT RACEWAY
Raceway partitions create private offices and cubicles with built-in power options for
computers and other electric equipment. Raceways provide convenient access for
data cables & electrical wiring to keep office spaces clean and clear of visible wires.
Panel is flame retardant to meet California 117 flammability standard. 1 3 /4” thick fabric
upholstered panels feature an interior engineered wood (MDF) frame and honeycomb
core covered with heavy tackable liner for structural strength. 4”H charcoal powder
coated steel raceways include UL approved modular electric components and cable
management openings for phone & data connectors. Removable, hinged raceway
covers allow easy wiring access. Includes adjustable leveling feet for uneven surfaces.
1 Year Limited Warranty. See our website for matching furniture and wood accent cap
options. All panel models available with window or whiteboard option.

GRAY (GY) BLUE (BL)

PANEL WITH ELECTRIC
RACEWAY INCLUDES DOUBLE
SIDED POWER BOXES
PASS-THRU CABLE
MULTI CIRCUIT
STARTER CABLE
SINGLE CIRCUIT
STEP 1 – PARTITIONS PLUG IN CABLE
Electric and non-electric panels can be connected together to place power where you need
it. Non-Electric Panels include a basic raceway without cabling. Pass-Thru Panels include
raceways with cables to connect to panels. Panels with Electric raceways include built-in STEP 3 – CABLES AND RECEPTACLES
double-sided power box, four circuit 1 receptacles and modular cables. Each power box can Starter Cable (Multiple Circuits, 80 receptacles max.) must 15AMP
accept up to 6 receptacles; 3 per side (additional Receptacles sold separately). Use included be installed to a junction box for a power source. Cable PLUG
Blanks to cover unused openings. 36”W Electric Panel includes one double-sided power box. pre-wired for 1-4 circuits. Plug In Cable (Single Circuit) easily
48” & 60”W Electric Panels include 2 double-sided power boxes. plugs into existing wall outlets for power. Choice of 15 AMP
(16 receptacles max.) or 20 AMP (20 receptacles max.) 115 volt 20AMP
Non-Electric Panel Pass-Thru Panel Panel With Electric Power plug. Additional circuit 1, 2, 3 (Isolated Ground) & 4 receptacles PLUG
W” x H” Model Model Model Boxes Blanks available in packages of four. Receptacle Removal Tool is
24 x 46 SC277660N SC277660P --- --- --- required when removing receptacles from power box.
36 x 46 SC240224N SC240224P SC240224E 1 2
48 x 46 SC240225N SC240225P SC240225E 2 8 Model Description RECEPTACLE
60 x 46 SC240226N SC240226P SC240226E 2 8 SC249054 Starter Cable 72” REMOVAL TOOL
24 x 64 SC277661N SC277661P --- --- --- SC249055 Starter Cable 144”
36 x 64 SC238635N SC238635P SC238635E 1 2 SC249056 Plug In Cable 72” 15AMP
48 x 64 SC238637N SC238637P SC238637E 2 8 SC249066 Plug In Cable 72” 20AMP
60 x 64 SC238639N SC238639P SC238639E 2 8 SC249057 Extended/Corner Cable
24 x 76 SC277662N SC277662P --- --- --- SC249061 Circuit 1 Receptacle (Pkg. 4)
36 x 76 SC238636N SC238636P SC238636E 1 2 SC249062 Circuit 2 Receptacle (Pkg. 4)
48 x 76 SC238638N SC238638P SC238638E 2 8 SC249063 Isolated Ground Receptacle (Pkg. 4)
60 x 76 SC238640N SC238640P SC238640E 2 8 SC249064 Circuit 4 Receptacle (Pkg. 4) RECEPTACLES 1, 2, 3(IG) & 4
Add color suffix: Gray (GY) or Blue (BL). SC249053 Receptacle Removal Tool
STEP 2 – CONNECTOR REMOVABLE, HINGED
Steel connectors join multiple partitions together and create various configurations. Use RACEWAY COVER
connectors with 1 Extended/Corner Cable to complete a 90° turn or span intersection. ALLOWS EASY ACCESS
Additional Extended/Corner Cables available separately (See Step 3). TO RECEPTACLES AND
With 1 CABLES
FOR SAME HEIGHT PANELS Without Extended/Corner
Description Cable Cable CABLE MANAGEMENT
Straight Connector Kit SC238644N --- OPENINGS FOR PHONE
Corner 90° Kit For 46”H Panel SC248989N SC248989P & DATA CONNECTORS
Corner 90° Kit For 64”H Panel SC238645N SC238645P (CABLES & CONNECTORS
Corner 90° Kit For 76”H Panel SC238641N SC238641P NOT INCLUDED)
Three Way Kit For 46”H Panel SC248990N SC248990P
Three Way Kit For 64”H Panel SC238648N SC238648P
Three Way Kit For 76”H Panel SC238642N SC238642P
Four Way Connector Kit SC238646N SC238646P
Wall Connector Kit SC238647N ---
End Base Cap (to finish panel end runs) SC249065 ---
FOR MULTI-HEIGHT PANELS
High-Low Straight Connector SC240227N ---
High-Low Corner 90° Kit For 46” Low Panel SC240255N SC240255P
High-Low Corner 90° Kit For 64” Low Panel SC240253N SC240253P EXTENDED/CORNER AVAILABLE AVAILABLE
High-Low Three Way Kit For Two 64” High Panel SC240258N SC240258P CABLE SEPARATELY SEPARATELY
High-Low Three Way Kit For Two 76” High Panel SC240257N SC240257P
Low-High Three Way Kit For Two 46” Low Panel SC240256N SC240256P CORNER 90° CONNECTION* THREE WAY CONNECTION* FOUR WAY CONNECTION*
Low-High Three Way Kit For Two 64” Low Panel SC240254N SC240254P *Connector kit includes 1 Extended/Corner Cable. Order additional Extended/Corner Cables as needed.
