INSTALLATION SPECIFICATIONS AND TOOLS

INSTALLATION SPECIFICATIONS AND TOOLS

INSTALLATION AIDS TRANSOM DRILLING FIXTURE

14 PIN BRACKET

91- 98234A 2
Used to assist drilling of the holes for the outboard engine transom bracket
mounting bolts.
8M0076435 Mercury/Mariner 30/40 hp. & above (2 cycle), 25 hp. Bigfoot & above (4‑Stroke),
Rounded edges and anti‑rotation and Force 40 hp. & above (1993 and newer).
Rigging aid for 14 pin data cable
CONTROL DRILLING FIXTURE
NUT

91-828363A 1
11-889664 Used to assist drilling of the holes for side mount control and panel mount control
(1.500‑18) Black Nylon mounting bolts.
For use with the Commander 2000 side mount and the Commander 3000 panel
DUAL STATION RIG HARNESS mount controls.
TRANSOM DRILL FIXTURE KIT

91-8M0119480
Kit contains one harness and two weather caps 91-866590A02
Used to temproarily rig a second station such that the vessel can be operated while
the second station is not installed (shipping, rigging installation, short term rework, Used to assist drilling of the holes for the MerCruiser transom plate mounting bolts.
etc) For MCM 1.6L Vazer models.
