Page 120 - Latin America Accessories Guide (2020) - 8M0163252

OUTBOARD

POWER TRIM ANODE SIDE POCKET ANODE OUTBOARD

8M0057772 826134T
Aluminum. Located on the bottom of the external power trim assembly. Aluminum
Fits the 150 Hp. EFI FourStroke outboard, 1B905505 and above. Located in side pockets on the gearhousing just above the cavitation plate.
Fits Mercury/Mariner 30‑300hp outboards and also fits Force 90 & 120hp 1995 and
ANODES - SIDE MOUNTED/POCKET newer outboards.
Priced individually, sold @ multiples of 3
Mercury Branded, Clamshell Package Point of Sale Packaged.
ANODE
826134Q
Aluminum
Located in side pockets on the gearhousing just above the cavitation plate.
Fits Mercury/Mariner 30‑300hp outboards and also fits Force 90 & 120hp 1995 and
newer outboards.
Priced individually, sold @ multiples of 3
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
826134T 3
Magnesium ‑ For freshwater use only. Do not use in saltwater applications.
Located in side pockets on the gearhousing just above the cavitation plate.
Fits Mercury/Mariner 35‑300hp outboards and Force 90 & 120hp 1995 and newer
outboards
18852M
Aluminum
ANODES - PROP NUT/SPOOL
ANODE
REPLACEMENT PROP NUT ANODE

819232
Aluminum, side mounted anode. 809662T
Fits Force outboards, 1991 (90E, 90H, 120H), 1992 (90A, 90C, 120A, 120C), and 2 in. Aluminum Anode Shell
1992‑1994 (90/120/150 0E000001‑0E093699). Replacement Shell for 809662A 1
ANODE PROP NUT ANODE KIT

823912 809664A 1
Aluminum, Round style. 1‑1/8 in. Shaft, 3/4 in. NF 16
Fits Mercury/Mariner 4/5 hp. 2‑cycle (MY1987 & newer), F4/5/6 hp. FourStroke Fits Mercury/Mariner 70 hp and higher outboards (except 225 EFI FourStroke);
(MY1999 & newer), F8/9.9 hp. FourStroke (MY2005 & newer), 15 hp. 2‑cycle Also fits MC‑I, R, MR, Alpha, Bravo One & TRS sterndrives (1970 & newer)
Seapro (MY2005 & newer), F25/30 EFI FourStroke (MY2006 & newer).

2020 Mercury Precision Parts & Accessories Guide 111
