QUICK REFERENCE GUIDE-OUTBOARD

QUICK REFERENCE GUIDE-OUTBOARD

QUICK REFERENCE TWOSTROKE CHARTS

75‑90‑115 Optimax 1B227000 & above

Description Part Number Page

Controls

Side Mount - MSC 4000 Series - Electric w/trim 15 ft. (4.6 m) harness 8M0083666
20 ft. (6.1 m) harness 8M0083667

Dual Engine Remote Control Kit (for side mount control stacking) 16909A 2 536

Panel Mount (with trim) - MPC 4000 Series (Gen II) Finger Release - Black Handle 8M0011213 528
Finger Release - Chrome Handle 8M0030550 528
Lock Bar 883710A02 529

Console Mount (single eng. with trim) - Commander 88688A25 536
Console Mount (single eng. with trim) - MCC 4500 Gen II 8M0059686 530

Console Mount (dual eng. with trim) - Commander Twin trim switches in handle 88688A22 537
Console Mount (dual eng. with trim) - MCC 4500 (Gen II) - single trim switch in handle 8M0075245 531

Throttle/Shift Cables (two per engine) - (Gen I) (Premium Series) 897977A03 thru 897977A50
Throttle/Shift Cables (two per engine) - (Gen II) (Premium Series) 897978A03 thru 897978A50

Instrumentation
All Models Max WOT Range = 5,000-5,750 RPM's Black Face 79-895283A06 479
QUICK REFERENCE GUIDE-OUTBOARD Tachometer - 8000 RPM - Admiral White Face 79-895283A26 484

Tachometer - 8000 RPM - Flagship

493
Black Face
79-895283Q06
White Face
500

79-895283Q26

79-895283A05
Black Face
Tachometer - 7000 RPM - Flagship
479

White Face
484
79-895283A25
Black Face
79-895283Q05
Tachometer - 7000 RPM - Admiral
492

79-895283A03
479
Black Face
79-895283A23
Tachometer - 6000 RPM - Flagship White Face 79-895283Q25 500
White Face
484
Tachometer - 6000 RPM - Admiral Black Face 79-895283Q03 492
White Face 79-895283Q23 500

Tachometer Harness - Analog 5 ft. length x 14 pin 84-892990T01 619
10 ft. length x 14 pin 84-892990T10 619
15 ft. length x 14 pin 84-892990T15 619

Speedometer - 65 MPH - Flagship Black Face 79-895285A03 480
White Face 79-895285A23 484
Speedometer - 65 MPH - Admiral Black Face 79-895285Q03 493
White Face 79-895285Q23 501
