SMARTCRAFT RIGGING

SMARTCRAFT PITOT SENSOR (SPEED) GPS EXTENSION CABLE
SMARTCRAFT RIGGING

8M0103315 84-879171T21
100 psi SmartCraft Pitot sensor for speed input 3.2 foot extension cable to be used with GPS Kit (8M0024918)
Verado Gen 5 350 HP engine only, all other Gen 5 Verado engines come with Pitot CAN P GPS signal for non Auto Pilot equipped boats
speed sensor 84-879171T22
PRESSURE TRANSDUCER KIT 6.6 foot extension cable to be used with GPS Kit (8M0024918)
CAN P GPS signal for non Auto Pilot equipped boats
84-879171T23
9.8 foot extension cable to be used with GPS Kit (8M0024918)
CAN P GPS signal for non Auto Pilot equipped boats
CAN H TO GTC CONNECTOR ADAPTER HARNESS

859210A 1
Speed pressure transducer is either mounted to the transom bracket or a location
near the engine. 100 PSI sensor is plumbed to a speed pickup tube and then wired
to the engine sensor plug included with SmartCraft Gauges.
Fits 2002 and newer OptiMax outboard engines at speeds less than 80 mph.
GPS KITS 84-8M0120136
Flat 4 pin CAN H connector to GTC connector adapter ‑ 0.5 meter
SMARTCRAFT OR NMEA2000 GPS ANTENNA Used in certain Joystick applications

8M0130792
SmartCraft or NMEA2000 capable GPS Antenna. Used with any system needing a
SmartCraft GPS source OR NMEA2000 GPS source. GPS autodetects which
system it is connected to and communicates correctly.
GPS can be used for all of the following applications: SC1000 gauge speed source,
SmartTow speed source, Active Trim without dash pad speed source or
NMEA2000 speed and position source.
