Page 833 - Latin America Accessories Guide (2020) - 8M0163252
P. 833

MERCURY PROPELLER TYPE                            MAXIMUS PROPELLER



      MERCURY PROPELLER TYPE
            BRAVO I PROPELLER












              48-831909A45                                         48-889975A65
            15.3 X 22 LH SS 4 BL                                15.6 X 24 LH SS 5 BL
              48-831909A55                                         48-889974A65
            15.3 X 22 LH SS 4 BL (Solid Hub)                    15.6 X 24 RH SS 5 BL
              48-831910A45                                         48-889965A65
            15.3 X 22 RH SS 4 BL                                15.6 X 26 LH SS 5 BL
              48-831910A55                                         48-889964A65
            15.3 X 22 RH SS 4 BL (Solid Hub)                    15.6 X 26 RH SS 5 BL
              48-831911A45                                         48-889967A65
            15.3 X 24 LH SS 4 BL                                15.6 X 28 LH SS 5 BL
              48-831911A55                                         48-889966A65
            15.3 X 24 LH SS 4 BL (Solid Hub)                    15.6 X 28 RH SS 5 BL
              48-831912A45                                         48-889969A65
            15.3 X 24 RH SS 4 BL                                15.6 X 30 LH SS 5 BL
              48-831912A55                                         48-889968A65
            15.3 X 24 RH SS 4 BL (Solid Hub)                    15.6 X 30 RH SS 5 BL
              48-831913A45                                         48-889971A65
            15.3 X 26 LH SS 4 BL                                15.6 X 32 LH SS 5 BL
              48-831913A55                                         48-889970A65
            15.3 X 26 LH SS 4 BL (Solid Hub)                    15.6 X 32 RH SS 5 BL
              48-831914A45                                         48-889973A65
            15.3 X 26 RH SS 4 BL                                15.6 X 34 LH SS 5 BL
              48-831914A55                                         48-889972A65
            15.3 X 26 RH SS 4 BL (Solid Hub)                    15.6 X 34 RH SS 5 BL
              48-831915A55
            15.3 X 28 LH SS 4 BL (Solid Hub)                    SPITFIRE X7 40 CT - 125 HP
              48-831916A55
            15.3 X 28 RH SS 4 BL (Solid Hub)                    The Spitfire X7 is 4‑blade stainless steel version of the Spitfire
              48-831917A55                                      aluminum propeller and is suited for 75‑125 horsepower applications
            15.3 X 30 LH SS 4 BL (Solid Hub)                    and 40‑60 horsepower command thrust with larger 4.25" gearcases.
                                                                With remarkable acceleration, top speed, and holding this is the
              48-831918A55                                      propeller of choice for these engines.
            15.3 X 30 RH SS 4 BL (Solid Hub)
              48-831919A55                                      Equipped with Flo‑Torq II hub kit 835257K 1
            15.3 X 32 LH SS 4 BL (Solid Hub)
              48-831920A55                                      Equipped with solid PVS plugs installed
            15.3 X 32 RH SS 4 BL (Solid Hub)

            MAXIMUS 90 CT - 400 HP
            The Maximus is a 5‑blade propeller well suited to performance offshore
            boats with high output sterndrives.
            Available in left and right hand rotation

            Equipped with Flo‑Torq II HD Solid hub kit 840389K06 for 1.25"
            propeller drive shafts
            Equipped with solid PVS plugs installed







            824                                       Phone: 954-744-3500; Fax: 954-744-3535; E-Mail: miami@mercmarine.com
