Page 962 - Latin America Accessories Guide (2020) - 8M0163252

HISTORICAL PROPELLER CHARTS

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
73142A40 10 16 AL 3 RH AVAIL.
FPM750 10 16 SS 3 RH N.L.A.
91818A 5 10 16 SS 3 RH AVAIL.
FPM738 10-1/8 15 AL 3 RH 48- 73140A45
73140A40 10-1/8 15 AL 3 RH AVAIL.
FPM739 10-3/8 15 AL 3 RH 48-816706A45
816706A40 10-3/8 15 AL 3 RH AVAIL.
FPM751 10-1/8 15 SS 3 RH 48-855862A46
76232A 5 10-1/8 15 SS 3 RH 48-855862A46
FPM752 10-1/4 14 SS 3 RH 48-855860A46
76230A 5 10-1/4 14 SS 3 RH 48-855860A46
FPM740 10-1/2 13 AL 3 RH 48-816704A45
816704A40 10-1/2 13 AL 3 RH AVAIL.
FPM753 10-3/8 13 SS 3 RH 48-855858A46
76228A 5 10-3/8 13 SS 3 RH 48-855858A46
FPM741 10-3/4 12 AL 3 RH 48-816702A45
816702A40 10-3/4 12 AL 3 RH AVAIL.
FPM742 11-7/8 12 AL 3 RH 48- 85632A45
85632A40 10-7/8 11 AL 3 RH AVAIL.
FPM754 10-5/8 12 SS 3 RH 48-855856A46
79792A 5 10-5/8 12 SS 3 RH 48-855856A46
FPM743 12 10-1/2 AL 3 RH 48- 42740A45
42740A10 12 10-1/2 AL 3 RH 48- 42740A45
FPM756 11-1/4 10 AL 3 RH 48- 73132A45
73132A40 11-1/4 10 AL 3 RH AVAIL.
FPM755 12-1/4 9 SS 3 RH
97868A10 12-1/4 9 SS 3 RH AVAIL.
FPM757 12-1/4 9 AL 3 RH 48- 87818A45
87818A10 12-1/4 9 AL 3 RH 48- 87818A45
FPM746 12-1/2 8 AL 3 RH 48- 42738A45
42738A10 12-1/2 8 AL 3 RH 48- 42738A45
Force 85‑150 and All L‑Drives Pre 1995 No Thru or Thru Hub Exhaust
85, 125 HP 1988‑1989
90, 120 HP 1990‑1994
90‑120 HP L Drive 1989‑1991
150 HP 1989‑1994 HISTORICAL PROPELLER CHARTS
150 HP L Drive 1991
15 Tooth Spline
Propeller Size Material Blades Style Quicksliver P/N Hub System
13 X 19 RH AL 3 Black Diamond Rubber Bushing
13-1/2 X 17 RH AL 3 Black Diamond Rubber Bushing
13-1/2 X 15 RH Cupped AL 3 Black Diamond Rubber Bushing
13-1/2 X 15 RH AL 3 Black Diamond Rubber Bushing

2020 Mercury Precision Parts & Accessories Guide 953
