Page 32 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)
P. 32

SMARTCRAFT INSTRUMENTS



             VESSELVIEW4 DISPLAY                                 WEATHER CAP-VIDEO CONNECTOR                          SMARTCRAFT INSTRUMENTS













                  8M6001767                             592.37        8M6001761                               5.99
             Display unit only with bezels, sun cover, weather caps, mounting hardware  Replacement weather cap for video connector on back of VesselView.
             and gasket.                                         Used on VV7, VV702 and VV703.
             VV4 display unit only for use as a Slave display on multi‑VV display
             installations.  Requires the VV4 adapter harness (8M0075066 ‑ 90 degree or  WEATHER CAP-NETWORK CONNECTOR
             8M0075079 ‑ straight), slave power harness (8M0077649) and NMEA2K
             connection to Primary VV display at that helm.
             VESSELVIEW 4 ADAPTER PLATE








                                                                      8M6001760                               3.28
                                                                 Replacement weather cap for network connector on back of VesselView.
                                                                 Used on VV7, VV702 and VV703.
                  8M0079348                              31.23   VESSELVIEW7 AND 70X VIDEO INPUT CABLE
             VesselView 4 adapter plate in brushed stainless steel.
             Adapter plate to install a VesselView 4 into the cutout for the previous
             generation VesselView.
             NMEA2000 STARTER KIT








                                                                      8M6003460                              30.86
                                                                 Add up to two video sources as inputs to your VesselView7 or 702 display.  Can be
                                                                 used for viewing numerous useful locations: the swim platform area, inside the
                                                                 engine compartment/bilge area, from the ski tower looking aft or down in the galley/
                                                                 cabin below
                  8M0110642                              35.56   Works with VV7, VV702 or VV703 and NTSC/PAL analog video signals
             Kit includes NMEA2000 power harness, 1 male termination resistor, 1
             female termination resistor and a "T" connector     VESSELVIEW MOBILE
             Whenever a NMEA2000 backbone is required, these are the basic
             components required to start that architecture
             VESSELVIEW REPLACEMENT NMEA2K WEATHER CAP









                                                                    84-8M0115080                            196.53
                                                                 Connect the SmartCraft digital data stream from your engine to your iOS or
                                                                 Android mobile device via BLE (Bluetooth Low Energy 4.0).
                  8M6001762                              3.47    Works with any SmartCraft‑capable 2003 or newer engine (from single to
             Replacement weather cap for NMEA2K connector on back of VesselView.  quad applications), 40 HP and higher (outboards, gas or diesel sterndrives and
                                                                 inboards, Joystick Piloting, Zeus pods and Racing products).
             Used on VV4, VV702, VV502 and VV703
             OEM Rigging & Accessories Guide & Price List                                                     19
