Page 622 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

MERCRUISER

TRAILERING CLIPS GEAR LUBE RESERVOIR KIT

To support drive in the tilt up position while trailering.

TRAILERING CLIP

865585A02 154.75
1 quart reservoir kit with float switch.
Designed to replace the smaller rectangular reservoir for added gear lube capacity.
Fits Bravo drives running under excessive loads in a heavy use environment.
817019T 2 19.70 GEAR LUBE RESERVOIR RELOCATION KIT
Fits MC‑I, R, MR, Alpha, Bravo & Vazer drives.
Priced & packaged in qty. of 2
Mercury Branded, Clamshell Package Point of Sale Packaged.

GEAR LUBE MONITOR KITS
GEAR LUBE MONITOR KIT MERCRUISER

806054A 1 26.00
Reservoir Relocation Kit. Used to relocate the "square" reservoir bottle from the
engine to the transom. This kit should be used when the installation of any other
accessory kit would interfere with the reservoir at its factory installed location.
Fits Alpha & Bravo models (1994 and newer)
OIL RESERVOIR STRAP

806193A49 106.35
Mounts on inner transom, connecting internally to the upper driveshaft housing.
Includes low gear lube warning sensor that connects to the engine audio warning
system. Warning feature requires that the Audio Warning System is installed on the
engine.
Fits Alpha One Gen II (s/n 0D491000 and above).
GEAR LUBE MONITOR KIT

808023T 7.00
For square oil reservoir bottle
AUDIO WARNING SYSTEM

WARNING HORN

806193A48 69.30
This kit converts the round 1 quart oil reservoir bottle to the new rectangular bottle.

816492A 6 51.25
Replacement horn for most audio alarms systems

OEM Rigging & Accessories Guide & Price List 609
