Page 618 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

OUTBOARD

MERCATHODE ELECTRODE REMOTE 3.0 US GAL (11 L) OIL TANK OUTBOARD

72958A 5 111.95 1257- 8742A21 135.00
Replacement electrode assembly for 88334 series Mercathode systems. Remote 3.0 US gal (11 L) Oil Tank with sender, complete with tank, lines,
floor mounting bracket and all hardware.
MERCATHODE REFERENCE ELECTRODE TESTER
REMOTE 3.0 US GAL (11 L) OIL TANK

91- 76675T 1 87.65
Use with a digital multimeter to test the function of Mercathode systems
1257- 8742A22 97.45
V-6 OUTBOARD RIGGING KITS Remote 3.0 US gal (11 L) Oil Tank without sender, complete with tank,
lines, floor mounting bracket and all hardware.
SMARTCRAFT RIGGING KIT Optional tank size for Mercury/Mariner 2 cycle outboards, to be used
wherever a pressurized oil reservoir system is already in use. This tank and
bracket assembly is only used in floor mounted applications.
REMOTE 3.0 US GAL (11 L) OIL TANK

8M0056278 453.62
Kit contains the following:
1257‑ 8742A21 Oil Tanks with Oil Senders (2) 1257- 8742A23 97.50
859223 Speed/Temperature Sensor (1)
84‑859743T 1 Haness to oil, fuel and paddle wheel (2) Remote 3.0 US gal (11 L) Oil Tank without sender, complete with tank,
84‑879981T30 SC1000R‑30, 30 ft. (9.1 meter) Data Harnesses (2) lines, mounting bracket and all hardware. Old Bracket Design
878492A16, 6‑Plug J Box (1) Optional tank size for Mercury/Mariner 2 cycle outboards, to be used
859318T 2 Weather Caps (2) wherever a pressurized oil reservoir system is already in use. This tank and
881175A 1 Male Connector Cap (1) bracket assembly may be optionally floor or wall mounted.
881176A 1 Female Connector Cap (1)
For dual application. Fits 2001‑2005 OptiMax Outboards, 2002‑2005 V‑6 EFI
Outboards and Pro Max Mercury Racing Outboards (when equipped with the 555
Electronic Control Module). The oil tank bracket may only be used as a floor
mounted application.

OEM Rigging & Accessories Guide & Price List 605
