Page 564 - Rigging and Accessories Guide (2022) - 8M0187689

OUTBOARD

OUTBOARD MOUNTING HARDWARE MOUNTING BOLT

Used for permanent mounting of an engine to the boat transom.

TRANSOM SUPPORT BRACKET

10- 67755005 7.55
Stainless mounting bolt, 2.5 in. (1.25 in. thread)
10-8M0131814 12.00
Stainless mounting bolt, 3.5 in. (1.25 in. thread)
67-896305001 30.48 MOUNTING BOLT
Used to reinforce the transom‑ transom bolts and washers used with this bracket to
strengthen the transom area where the engine in mounted.
TRANSOM SUPPORT WASHER

10-814259 11.00 OUTBOARD
Stainless mounting bolt 1/2 in. x 4.00 in. (2.25 in. Thread)
MOUNTING BOLT
67-896392 7.31
Used to reinforce the transom‑ transom bolts and washers used with this
reinforced washer to strengthen the transom area where the engine in mounted.
MOUNTING BOLT

10-8M0028080 10.00
Optional 7 1/2" Length Mounting Bolt (2.75 in. thread)
Fits current Mercury/Mariner 40 hp. and above outboards (2 cycle and FourStroke),
and also fits Force 40‑120 hp. outboards (USA 0E009500 and Newer).
10-8M0149747 5.25 MOUNTING BOLT
Standard 4 1/2" Length Mounting Bolt (2.25 in. thread)
Fits current Mercury/Mariner 40 hp. thru V‑6 outboards (2‑cycle and FourStroke),
and also fits Force 40‑120 hp. outboards (USA 0E009500 and Newer). Furnished
standard with the 135‑175 hp. Verado outboards.
MOUNTING BOLT

10-8M0032860 11.20
Stainless mounting bolt, 8 in. (2.75 in. thread)
10-8M0038370 5.65
Stainless mounting bolt, 1/2 in. x 5.50 in. (3.25 in. Thread)
Shipped standard with the 200/225/250/275 hp. Verado outboard.
10- 67755 2 9.65
Optional 6 1/2" Length Mounting Bolt (2.75 in. thread)
Fits current Mercury/Mariner 40 hp. and above outboards (2 cycle and FourStroke),
and also fits Force 40‑120 hp. outboards (USA 0E009500 and Newer).

2022 OEM Rigging & Accessories Guide & Price List 551
