P. 506

ANALOG INSTRUMENTS



             ADMIRAL SPEEDOMETER                                 ADMIRAL WATER TEMPERATURE GAUGE                      ANALOG INSTRUMENTS













                79-895285Q64                  29C92      49.87      79-895287Q61                  23C39      38.98
             Anti‑fog lens. 10‑80 MPH. 270 degree dial sweep. Black face and Chrome bezel;  Anti‑fog lens. 100 deg.‑240 deg.F gauge. Black face and Chrome bezel; red
             red graduations. Includes 20 ft.(6.1 m) of tubing. Fits 3‑3/8 in. (85 mm) hole in  graduations.
             dash.                                               Fits all MCM/MIE gasoline engines and Mercury/Mariner V‑6 outboards. Sender, if
             Quicksilver Branded, Box Point of Sale Packaged.    not already installed on the outboard, must be purchased separately.
                                                                 Quicksilver Branded, Box Point of Sale Packaged.
             ADMIRAL SPEEDOMETER
                                                                 ADMIRAL WATER TEMPERATURE GAUGE











                79-895285Q68                  39C42      65.70
             Anti‑fog lens. 10‑40 Knots. 270 degree dial sweep. Black face and Chrome bezel;  79-895287Q62  23C39  38.98
             red graduations. Includes 20 ft.(6.1 m) of tubing. Fits 3‑3/8 in. (85 mm) hole in  Anti‑fog lens. 60 deg.‑220 deg.F gauge. Black face and Chrome bezel; red/white
             dash.                                               graduations.
             Quicksilver Branded, Box Point of Sale Packaged.    Fits Mercury/Mariner 25 thru 115 FourStroke, 225 FourStroke, 40 (3 & 4 cyl.), 45,
             ADMIRAL VOLT METER                                  50/60 (3 cyl.), and 70 to 125 hp ; and 1993 and newer Force outboards (Force
                                                                 models must order sender FA299791) Senders must be ordered seperately
                                                                 Quicksilver Branded, Box Point of Sale Packaged.
                                                                 ADMIRAL WATER PRESSURE GAUGE









                79-895286Q61                  15C23      25.38
             Anti‑fog lens. Black face and Chrome bezel; red/white graduations. Outboards
             require a tachometer harness or ignition/choke assembly for connection.
             Quicksilver Branded, Box Point of Sale Packaged.       79-895288Q61                  33C18      55.30
                                                                 Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
                                                                 Black face and Chrome bezel; red graduations. Complete kit. Includes 25 ft.(7.6 m)
                                                                 of tubing and hardware.
                                                                 Replacement hose not sold separate, obtain locally.
                                                                 Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
                                                                 1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
                                                                 outboards require a reducer fitting p/n 22‑86306.
                                                                 Quicksilver Branded, Box Point of Sale Packaged.














             2019 US Accessories Guide                                                                      493
