Page 664 - US ACCESSORIES GUIDE (2019)
P. 664
ELECTRICAL
SMARTCRAFT JUNCTION BOX SMARTCRAFT J-BOX TERMINATOR/RESISTOR ELECTRICAL
878492K18 88C43 147.38 859318T 1 8C90 14.83
8‑Way SmartCraft Junction Box with (4) weather caps. SmartCraft Yellow 10‑pin Terminator/Resistor
Provides connection/distribution point for multiple components on CAN Bus Provides CAN Bus termination for CAN P network.
system. 859318B 1 8C36 13.93
878492T18 76C64 127.73 SmartCraft Yellow Junction Box Terminator/Resistor
8‑Way SmartCraft Junction Box without weather caps. Provides CAN Bus termination where installed
Provides connection/distribution point for multiple components on CAN Bus Priced individually, sold @ multiples of 24
system.
TERMINATOR ASSEMBLY
SMARTCRAFT WEATHER CAP
8M0055652 11C35 18.92
859318T 2 5C28 8.80 SmartCraft Red Terminator Can 1/P & H
Weather Cap for SmartCraft Junction Box
Provides weather protection at unused junction box connection points RESISTOR- TERMINATION- 2 PIN
859318B 2 4C98 8.30
Weather Cap for SmartCraft Junction Box
Provides weather protection at unused junction box connection points
Priced individually, sold @ multiples of 24
10 PIN WEATHER CAP
893388A01 7C73 12.88
Blue 2‑pin terminator/resistor
Provides CAN bus termination for CAN Networks.
HELM MPR 2 PIN WEATHER CAP
888507T 4C20 7.00
10 pin weather cap with mounting tab.
Used for harnessing that could plug into a Junction Box.
86-8M0054244 4C45 7.42
GT280 2 pin male weather cap.
Used on Joystick (Zeus, Axius and JPO) applications for the Helm MPR connection
harness 8M2021476.
2019 US Accessories Guide 651
