STEERING

64-891666Q04 511A38 730.54 NON VENTED CAP
Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on singles
and 6.5 on dual cylinders
Compact design
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
MERCURY HYD BOLT-ON STEERING KIT- STD -W/O
HOSES

19-898432 12C99 21.65
Required for dual station installations of steering system.
REMOTE FILL KIT FOR HYDRAULIC STEERING

898349A02 816A02 1165.74
This kit includes a standard helm (1.5Cu Inch) with all the needed components to
STEERING most robust hydraulic system in the market. The cylinder was tested to all Verado
install the helm along with a bolt‑on cylinder with hardware . This bolt‑on kit is the
standards for load and strength. The kit also includes high strength machined
stainless steel screws that are used at each attachment point. Order Verado hoses
897982K__ series separately
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax 64-889934A05 26C37 43.94
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti) (Use with Remote fill adapter for rear mount and tilt mount Hydraulic pumps
Power Steering Hoses 8M0046914 thru 8M00469932) Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
MERCURY HYD BOLT-ON STEERING KIT-TILT -W/O
HOSES HYDRAULIC HELM STEERING FLUID

898349A03 858A46 1226.37 92-858078Q01 11C14 19.23
This kit includes a Tilt helm (1.5 Cu Inch) with all the needed components to install Meets H5606G military specifications
the helm along with a bolt‑on cylinder with hardware and remote fill kit. This For use in non‑power hydraulic steering systems such as, MerCruiser compact
bolt‑on kit is the most robust hydraulic system in the market. The cylinder was hydraulic helm steering systems and bolt‑on steering systems such as SeaStar®
tested to all Verado standards for load and strength. The kit also includes high by Teleflex®, Inc.
strength machined stainless steel screws that are used at each attachment point.
Order Verado hoses (897982K__) separately Priced individually, sold @ multiples of 6
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax 946 mL (32 fl oz) plastic bottle
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti) (Use with Quicksilver Branded
Power Steering Hoses 8M0046914 thru 8M00469932)
HYDRAULIC STEERING ARM
VENTED HELM CAP-VCAP

898082A03 92C22 153.70
64-891667Q01 6C26 10.44 This arm attaches the cylinder to the engine for 1.5L OptiMax engines. Remove
VCAP Vented helm cap for use on Q/S helms 891665Q02 and 891666Q01 existing arm on 898349A01 cylinder and replace it with this arm for proper
clearances
1.5L OptiMax engines
