STEERING

Model Model Notes Year Range Serial # Range Tiller Handle Kit Part Number Handle Color Shift Attaching Kit
135-200 L4 Verado DTS, Big Tiller, Power Steer 2006 - 2021 USA 1B227000 and up 8M0134609 Black N/A
150 EFI FourStroke Big Tiller, Power Steer 2011 - 2021 USA 1B905505 and up 8M0134604 Black N/A
(2) Conversion of power trim models will require a suitable power trim switch.
(4) Transom mounted ignition keyswitch 15000A 7 required to complete conversion.
(5) Transom mounted ignition keyswitch 15000A 7 and neutral interlock 87-813960A 4 required to complete conversion.
(7) Electric start models requires tiller handle harness button 87-823609A 7 or transom monted keyswitch 15000A 7 to complete the conversion.
(9) Models requiring Mercury style ended throttle/shift cables.
(10) Models requiring SAE style ended throttle/shift cables.

TIE BAR KITS 8M0097267 529.14
WARNING: Cancer - www.P65Warnings.ca.gov
HEAVY DUTY TIE BAR KIT- DUAL Heavy Duty 36 inch Tie Bar allows two engines to be attached together +/‑
1.25 inches.
Tie Bar has been engineered for higher horse power applications with
improved retaining design.
36 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines.
BUSHING KIT FOR USAGE WITH LATHAM BENT TIE
BARS

23-8M0156413 8.31
8M0096314 519.09 Contains 4 pcs of bushing 8M0092909.
WARNING: Cancer - www.P65Warnings.ca.gov Used in applications where Latham bent tie bars are required to accommodate
Heavy Duty 26 inch Tie Bar allows two engines to be attached together +/‑ engine mounting height deltas of 3+ inches. This bushing allows the Latham tie
bar to pair up with the Mercury tie bar head.
1.25 inches.
Tie Bar has been engineered for higher horse power applications with HEAVY DUTY TIE BAR ADD AN ENGINE KIT
improved retaining design.
26 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines
8M0096315 522.72
WARNING: Cancer - www.P65Warnings.ca.gov
Heavy Duty 28 inch Tie Bar allows two engines to be attached together +/‑
1.25 inches.
Tie Bar has been engineered for higher horse power applications with
improved retaining design.
28 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines.
8M0096316 529.62
WARNING: Cancer - www.P65Warnings.ca.gov 8M0096320 446.39
Heavy Duty 30 inch Tie Bar allows two engines to be attached together +/‑
1.25 inches. WARNING: Cancer - www.P65Warnings.ca.gov STEERING
Tie Bar has been engineered for higher horse power applications with Add An Engine 26 inch Tie Bar allows triple and quad engines to be
improved retaining design. attached together +/‑ 1.25 inches.
30 +/‑ 1.25 inches Tie Bar has been engineered for higher horse power applications with
2.6L L6 Gen 5 and 4.6L Verado Engines. improved heavy duty design.
26 +/‑ 1.25 inches
8M0096317 532.13 2.6L L6 Gen 5 and 4.6L Verado Engines.
WARNING: Cancer - www.P65Warnings.ca.gov 8M0096321 448.96
Heavy Duty 32 inch Tie Bar allows two engines to be attached together +/‑ WARNING: Cancer - www.P65Warnings.ca.gov
1.25 inches.
Tie Bar has been engineered for higher horse power applications with Add An Engine 28 inch Tie Bar allows triple and quad engines to be
improved retaining design. attached together +/‑ 1.25 inches.
32 +/‑ 1.25 inches Tie Bar has been engineered for higher horse power applications with
2.6L L6 Gen 5 and 4.6L Verado Engines. improved heavy duty design.
28 +/‑ 1.25 inches
8M0096319 535.83 2.6L L6 Gen 5 and 4.6L Verado Engines.
WARNING: Cancer - www.P65Warnings.ca.gov 8M0096322 452.71
Heavy Duty 34 inch Tie Bar allows two engines to be attached together +/‑
1.25 inches. WARNING: Cancer - www.P65Warnings.ca.gov
Tie Bar has been engineered for higher horse power applications with Add An Engine 30 inch Tie Bar allows triple and quad engines to be
improved retaining design. attached together +/‑ 1.25 inches.
34 +/‑ 1.25 inches Tie Bar has been engineered for higher horse power applications with
2.6L L6 Gen 5 and 4.6L Verado Engines. improved heavy duty design.
30 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines.
