STEERING

HELM DUAL STATION - TILT ELECTRIC STEERING HELM CORE KIT

98-8M0157716 960.25
Electric steering helm used in Joystick Piloting applications and Single Outboard
Electric Steering.
DTS Controls
895818K12 385.13
Power Steering dual helm with a tilt position mount. Includes cover, COVER
bracket and mounting hardware. (40 CM3) Needs 32‑892825___ hose to
attach pressure lines (lengths come in 8 ft to 25 ft lengths) Use as primary
station when using dual helms or stations. Use standard helm as the secondary
station. Requires tilt mechanism to be ordered separately.
Multiple Engine 150 4 strokes and Optimax (No Single engines) , Verado 135‑200
4 cylinder, 200‑300 Verado 6 cylinder, 350 SCI
HELM - POWER STEERING - STANDARD

8M0162224 251.23
Power Steering helm with a fixed position mount. Includes cover, bracket 893405T 105.10
and mounting hardware.(80 CM3) Power Trim/Steering Cylinder cover. Counter Rotation
Multiple Engine or high steering load applications, 300‑450HP. Intended 200‑400 Hp Verado
for use only when paired with the Gen C HD pump.
CYLINDER - HYDRAULIC OR POWER STEERING
HELM - POWER STEERING -TILT

8M0162225 295.64
Power Steering Helm 80 CM3 Tilt. Includes all brackets and hardware
needed to install helm.
Recommended for triple and quad engine installations.
Multiple Engine or high steering load applications, 300‑450HP. Intended for use
only when paired with the Gen C HD pump.
POWER STEERING - TILT HELM MECHANISM
898349A11 333.98
Cylinder designed to meet all Power Steering strength and performance
requirements. This cylinder is the most robust design in the market.
Includes all hardware to mount this cylinder including the strongest bolts to
attach to the engine.
8M6003708 210.94 Verado 175‑200 ‑ both Power Steering or Hydraulic V6/1.5 Opti Max Hydraulic ‑ STEERING
Power Steering Helm Tilt Mechanism primarily for usage on boats with electric 1.5L Opti needs to order arm 898082A03 to provide clearance
75‑150 4 stroke engines.
helms. Includes all brackets and hardware needed to install.
Intended for usage on boats with electric helms. Most of these boats have joystick CYLINDER - HYDRAULIC OR P/S- COUNTER ROTATION
capabilities but not all.
POWER STEERING - FLUSH HELM MECHANISM

98-8M6006473 492.01
Power Steering Helm Flush Mechanism primarily for usage on boats with
electric helms. Includes all brackets and hardware needed to install.
Intended for usage on boats with electric helms. Most of these boats have
joystick capabilities but not all. Flush helm is a benefit to boats with particularly
large steering wheels.
898349A14 384.34
Port ot counter rotation cylinder designed to meet all Power Steering
strength and performance requirements. This cylinder is the most robust
design in the market. Includes all hardware to mount this cylinder including
the strongest bolts to attach to the engine
Verado 135‑200 ‑ both Power Steering or Hydraulic. Multiple Engines
V6/1.5 Opti Max Hydraulic ‑ 1.5L Opti needs to order arm 898082A03 to provide
clearance 75‑115 4 stroke engines Multiple OtiMax engines ‑ P/S 150 4 Stroke
engines.
