Page 392 - OEM RIGGING AND ACCESSORIES GUIDE (2021) - 8M0174477

MERCURY PROPELLER TYPE - STAINLESS STEEL

BRAVO THREE 48-8M8022459 486.08
13.8 X 26 RH SS 3 BL ‑ Rear
48-8M8022469 486.08
15 X 28 LH SS 4 BL ‑ Front
48-8M8022479 486.08
13.5 X 28 RH SS 3 BL ‑ Rear
BRAVO THREE PROPELLER (MATTE FINISH)
BRAVO THREE 48-8M8022340 429.17
16 X 19 LH SS 4 BL ‑ Front
This amazing twin‑prop drive system features stainless steel props: A 48-8M8022350 429.17
large diameter forward propeller and a smaller diameter aft propeller for 14.4 X 19 RH SS 3 BL ‑ Rear
unbelievable handling and boat control. 48-8M8022360 429.17
16 X 20 LH SS 4 BL ‑ Front
Bravo Three features 4‑blade front, 3‑blade rear set that offers better
acceleration performance and enhanced holding. Bravo Three is 48-8M8022370 429.17
available in both matte and high polish finishes. Mixing with old style 14.4 X 20 RH SS 3 BL ‑ Rear
three blade front three blade rear Bravo Three propellers is not 48-8M8022380 429.17
recommended. For part number information on the old Bravo Three 15.9 X 21 LH SS 4 BL ‑ Front
propellers (2008 and earlier) see the historical propeller charts section 48-8M8022390 429.17
of this guide.
14.3 X 21 RH SS 3 BL ‑ Rear
Use with: 48-8M8022400 429.17
805100 Aft Thrust Washer 15.8 X 22.5 LH SS 4 BL ‑ Front
805101T Forward Thrust Washer 48-8M8022410 429.17
862907 Aft Prop Nut 14.3 X 22.5 RH SS 3 BL ‑ Rear
8M0105210 Forward Prop Nut
48-8M8022420 429.17 MERCURY PROPELLER TYPE - STAINLESS STEEL
15.5 X 24 LH SS 4 BL ‑ Front
48-8M8022430 429.17
14 X 24 RH SS 3 BL ‑ Rear
48-8M8022440 429.17
15.3 X 26 LH SS 4 BL ‑ Front
BRAVO THREE PROPELLER (HIGH POLISH FINISH)
48-8M8022450 429.17
13.8 X 26 RH SS 3 BL ‑ Rear
48-8M8022460 429.17
15 X 28 LH SS 4 BL ‑ Front
48-8M8022470 429.17
13.5 X 28 RH SS 3 BL ‑ Rear
BRAVO THREE DIESEL

Designed for use on heavier boats high HP diesels. A large diameter
four‑blade front propeller coupled with a smaller diameter, three‑blade
rear propeller provides unmatched acceleration, tracking and handling
with diesel applications. Extra cup built in to the trailing edges of both
48-8M8022349 486.08 front and rear props captures the torque generated by today’s
16 X 19 LH SS 4 BL ‑ Front turbocharged diesel engines. Best performing propeller for modern
48-8M8022359 486.08 diesel engines matched to Bravo III drives.
14.4 X 19 RH SS 3 BL ‑ Rear
48-8M8022369 486.08 Key Features:
16 X 20 LH SS 4 BL ‑ Front Left‑hand, 4‑blade forward and right‑hand, 3‑blade rear propellers.
Enhanced blade cup for improved planing performance and fuel
48-8M8022379 486.08 economy.
14.4 X 20 RH SS 3 BL ‑ Rear Recommended for 260‑370 H.P. diesel engines.
48-8M8022389 486.08 Fit for use on standard Bravo Three, Bravo Three X and Bravo Three
15.9 X 21 LH SS 4 BL ‑ Front XR drives.
48-8M8022399 486.08 Bravo Three Diesel Propellers feature a durable matte finish
Moving from the standard Bravo Three propellers to the Bravo Three
14.3 X 21 RH SS 3 BL ‑ Rear Diesel props will result in one inch pitch decrease to match the same
48-8M8022409 486.08 RPM.
15.8 X 22.5 LH SS 4 BL ‑ Front
48-8M8022419 486.08 Use with:
14.3 X 22.5 RH SS 3 BL ‑ Rear 805100 Aft Thrust Washer
805101T Forward Thrust Washer
BRAVO THREE PROPELLER 862907 Aft Prop Nut
48-8M8022429 486.08 8M0105210 Forward Prop Nut
15.5 X 24 LH SS 4 BL ‑ Front High Polish Finish
48-8M8022439 486.08
14 X 24 RH SS 3 BL ‑ Rear High Polish Finish
BRAVO THREE PROPELLER (HIGH POLISH FINISH)
48-8M8022449 486.08
15.3 X 26 LH SS 4 BL ‑ Front
2021 OEM Rigging & Accessories Guide & Price List 379
