Page 1032 - Quicksilver Product Guide (2020) - 8M0163242

DRIVE SYSTEMS

U-JOINT CHART

Universal Joints
Model Year Range Serial # Range U-Joint Assy. U-Joint Cross & U-Joint Center U-Joint Yoke - Drive U-Joint Yoke -
Bearing Socket Gear End Coupler End
IA/IB/IC 1964 1684188 - 1777798 N.L.A. 75832T 1 39383 1 46020T02 N.L.A.
IA/IB/IC EZ 1965 - 1966 1776349 - 2065186 N.L.A. 75832T 1 39383 1 46020T02 N.L.A.
120/140 1967 - 1982 2062141 - 6225576 N.L.A. 75832T 1 39383 1 46020T02 N.L.A.
470/485 1976 - 1982 4208730 - 6225575 N.L.A. 75832T 1 39383 1 46020T02 N.L.A.
160/165 1967 - 1981 2065190 and up N.L.A. 75832T 1 39383 1 46020T02 N.L.A.
888/225/233 1971 - 1977 3106717 and up 814819A 2 75832T 1 39383 1 46020T02 59830A 7
898/228/250/260 1977 - 1982 4782330 - 6225576 814819A 2 75832T 1 39383 1 46020T02 59830A 7
R/MR/Alpha One 1983 - 1986 6225577 - 0B418818 814819A 2 75832T 1 39383 1 46020T02 59830A 7
Alpha One 1986 - 1990 0B418819 - 0D469858 814819A 2 75832T 1 39383 1 46020T02 59830A 7
Alpha One SS 1986 - 1989 0A545004 and up 814819A 2 75832T 1 39383 1 46020T02 59830A 7
Alpha One Gen II 1991 - 1993 0D469859 - 0D869999 814819A 2 75832T 1 39383 1 46020T02 59830A 7
Alpha One Gen II 1993 - 1997 0D870000 - 0K999999 814819A 2 805536A 2 39383 1 46020T02 814819A 3
Alpha One Gen II 1998 - 2001 0L100040 - 0M400411 864281A 2 805536A 2 39383 1 853635 814819A 3
Alpha One Gen II 2002 - 2019 0M400412 and up 864281A 2 865496A02 865503T 864282T 864281A01 MERCURY® MERCRUISER®
Vazer 2007 - 2009 0W995000 and up 864281A 2 865496A02 865503T 864282T 864281A01
Bravo I/II/III 1988 - 2002 0B664190 - 0M111207 864244A 2 75832T 1 39383 1 12784 59830A 7
Bravo I/II/III 2002 - 2019 0M111208 and up 864244A 2 865496A02 865503T 864245T 864244A01
Bravo X/XR/XZ 2000 - 2003 0M100001 - 0M750174 865425A03(3) 862132T N/A N/A N/A
Bravo X/XR/XZ 2003 - 2019 0M750175 and up 865425A03(4) 866136A01 866137T 866134T 866133A01
Bravo XR/XZ (Integrated Transom) 2000 - 2003 0M100001 - 0M750174 865425T02(3) 862132T N/A N/A N/A
Bravo XR/XZ (Integrated Transom) 2003 - 2019 0M750175 and up 865425T02(4) 866136A01 866137T 866134T 866135A01
Blackhawk 1994 - 1995 0F186717 and up 864244A 2 75832T 1 39383 1 12784 59830A 7
II 1962 - 1963 1474909 - 1602185 N.L.A. 75832T 1 N/A N/A N/A
II 1864 - 1969 1602186 - 2671321 N.L.A. 75832T 1 39383 1 N.L.A. N.L.A.
215H 1970 2782203 - 2909034 N.L.A. 75832T 1 39383 1 N.L.A. 57749A 1
215E 1970 - 1972 2909035 - 2915034 N.L.A. 75832T 1 39383 1 N.L.A. N.L.A.
TR/TRS 1973 - 1993 3377316 and up N.L.A.(1) 75832T 1 39383 1 N.L.A. 62784A 1(1)
TR/TRS 1973 - 1993 3377316 and up N.L.A.(2) 75832T 1 39383 1 N.L.A. 57749A 1(2)
(1) Mercury Transmission
(2) B/W Transmission
(3) Meritor Assembly
(4) GKN Assembly

GEAR REPAIR KITS - DRIVESHAFT HOUSING 43-803116T 1
22‑20 teeth, 1.50 ratio
Fits R, MR, Alpha One & SS (1983‑1990)
UPPER GEAR REPAIR KIT
43-803112T 1
24‑24 teeth, 1.65 ratio
Fits R, MR & Alpha One (1983‑1990)
43-803114T 1
17‑19 teeth, 1.84 ratio
Fits R, MR & Alpha One (1983‑1990)
43-803101T 1
20‑24 teeth, 1.98 ratio
Fits R, MR & Alpha One (1983‑1990)

43-803115T 1
20‑16 teeth, 1.32 ratio
Fits R, MR, Alpha One & SS (1983‑1990)

Quicksilver Product Guide 1023
