DRIVE SYSTEMS

GEAR BEARING RACE 23-864596058
.058 in. thick (Brown)
Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23-864596059
.059 in. thick (White)
Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23-864596060
.060 in. thick (Orange)
Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23-864596061
.061 in. thick (Green)
Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23- 87560091 23-864596062
.091 in. thick (Red) .062 in. thick (Yellow)
Fits Bravo drives (s/n 0B664190‑0L999999) Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23- 87560094 23-864596063
.094 in. thick (Light Blue) .063 in. thick (Red)
Fits Bravo drives (s/n 0B664190‑0L999999) Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23- 87560097 .064 in. thick (Light Blue)
23-864596064
.097 in. thick (Green)
MERCURY® MERCRUISER® .051 in. thick .065 in. thick (Black)
Fits Bravo drives (s/n 0B664190‑0L999999)
Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23-861782051
23-864596065
Fits Bravo drives (s/n 0B664190‑0L999999) with the new Replacement gear sets.
Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
23-861782054
23-864596066
.054 in. thick
.066 in. thick (Pink)
Fits Bravo drives (s/n 0B664190‑0L999999) with the new Replacement gear sets.
23-861782057
.057 in. thick
Fits Bravo drives (s/n 0B664190‑0L999999) with the new Replacement gear sets. Fits 2000 & newer Bravo drives (s/n 0M100001 and above)
BEARING CHART - DRIVESHAFT HOUSING

Drive Shaft Housing Bearings

Model Gear Ratio Year Range Serial # Range Bearing - Drive Gear Bearing - Driven Gear Bearing - Upper Cover
I ALL 1963 1534570 - 1684187 N.L.A. 31- 32573A 1 31- 32575T 1
IA/IB/IC & EZ Shift ALL 1964 - 1966 1684188 - 2065186 31- 35988A12 31- 35990A 1 31- 32575T 1
120/140 1.98 1967 2062141 - 2187468 31- 35988A12 31- 35990A 1 31- 35990A 1
120/140 1.98 1967 - 1971 2187469 - 3134193 31- 35988A12 31- 35990A 1 31- 32575T 1
120/140 1.98 1971 - 1982 3213658 - 6225576 31- 35988A12 31- 35990A 1 31- 61100A 1
470/485 1.84 1976 - 1982 4208730 - 6225575 31- 35988A12 31- 35990A 1 31- 61100A 1
160 1.68 1967 2065190 - 2182197 31- 35988A12 31- 35990A 1 31- 35990A 1
160 1.68 1967 - 1971 2182198 - 3134193 31- 35988A12 31- 35990A 1 31- 32575T 1
165 1.65 1971 - 1981 3213658 and up 31- 35988A12 31- 35990A 1 31- 61100A 1
888 1.50 1974 - 2019 3784375 and up 31- 35988A12 31- 35990A 1 31- 61100A 1
225-S 1.50 1974 3856268 - 4200499 31- 35988A12 31- 35990A 1 31- 61100A 1
233 1.32 1975 - 1977 4200500 and up 31- 35988A 3 31- 66818A 1 31- 61100A 1
898/228 1.65 1977 - 1982 4782330 - 6225576 31- 35988A12 31- 35990A 1 31- 61100A 1
250 1.32 1977 4791300 - 4898729 31- 35988A 3 31- 66818A 1 31- 61100A 1
260 1.50 1978 - 1982 4898730 - 6225576 31- 35988A12 31- 35990A 1 31- 61100A 1
R/MR/Alpha One 1.98/1.84/1.65/1.50 1984 - 1990 6225577 - 0D469858 31- 35988A12 31- 35990A 1(8) 31- 61100A 1
R/MR/Alpha One 1.50 1984 - 1990 6225577 - 0D469858 31- 35988A12 31- 32573A 1(6) 31- 61100A 1
R/MR/Alpha One 1.32 1984 - 1990 6225577 - 0D469858 31- 35988A 3 31- 66818A 1(7) 31- 61100A 1
R/MR/Alpha One 1.50 HEAVY DUTY 1984 - 1990 6225577 - 0D469858 N.L.A. 31- 32573A 1(6) 31- 61100A 1
Alpha One SS 1.32 1986 - 1989 0A545004 and up 31- 35988A 3 31- 66818A 1 31- 61100A 1
Alpha One SS 1.50 1986 - 1989 0A545004 and up N.L.A. 31- 32573A 1 31- 61100A 1
Alpha One Gen II 2.40/1.98/1.84/1.65 1991 - 1995 0D469859 - 0F679999 31- 35988A12 31- 35990A 1 31- 61100A 1
Alpha One Gen II 1.50 1991 - 1995 0D469859 - 0F679999 31- 35988A12 31- 32573A 1 31- 61100A 1
