PROPELLER HARDWARE AND ACCESSORIES

FLO-TORQ HUB KIT OMC COBRA / VOLVO SX FLO-TORQ II HUB KIT YAMAHA

8M0119083 8M0075402
835467 Forward thrust washer 8M0064826 Forward thrust washer
879637 Plastic drive sleeve 879637 Plastic drive sleeve
850330Q Aft adapter 826074Q1 Aft adapter
8M0107489 Nut 887972 Spacer
89961 Cotter Pin 859939 Nut
8M0118204 Washer Spacer 89961 Cotter Pin
OMC Cobra an Volvo SX stern drive 19‑tooth spline 1996 & Newer. Caution! 115‑250 HP VMAX SHO 4 stroke outboards using a two piece thrust washer.
When installing stainless steel propellers, remove the anode to bearing carrier and
check clearance before operation. Use part number 835274Q1 if OEM hub uses single piece thrust washer
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT YAMAHA
FLO-TORQ II HUB KIT
835274Q 1
853948 1 Forward thrust washer QUICKSILVER® PROPELLERS
879637 Plastic drive sleeve
826074Q1 Aft adapter
887972 Spacer
859939 Nut
89961 Cotter Pin
150‑300 HP 4 stroke outboards and 115‑250 VMAX SHO outboards using OEM
single piece thrust washer
Use p/n 8M0075402 for 115‑250 VMAX SHO outboards using OEM two piece
thrust washer
835272Q 1
853555 Forward thrust washer Quicksilver Branded, Hanging Box Point of Sale Packaged.
879637 Plastic drive sleeve FLO-TORQ REFLEX DRIVE SLEEVE
826074Q1 Aft adapter
850076 Spacer
859935 Nut
89961 Cotter Pin
Yamaha outboards (50‑100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT YAMAHA

8M0047148
Plastic drive sleeve Flo‑Torq Reflex Composite Drive Sleeve
DRIVE SLEEVE

835271Q 2
853948 Forward thrust washer
879637 Plastic drive sleeve
826074Q1 Aft adapter
850076 Spacer
859939 Nut
89961 Cotter Pin
Yamaha 150‑300 HP HPDI 2‑stroke outboards using a one piece thrust washer
and all Yamaha stern drives
Quicksilver Branded, Hanging Box Point of Sale Packaged.
835290Q 1
Plastic drive sleeve Flo‑Torq II
Quicksilver Branded, Hanging Box Point of Sale Packaged.
