ANALOG INSTRUMENTS

FITTING (90 DEGREE) TEMPERATURE SENDER KIT

22-891533 12415A 2
90 degree fitting used on pressure sensor kit. Allows adding a temperature sender to outboards equipped with a factory built
2.5XS 2.5L DFI 0T997974 thru 1E000796 coastal flush. Includes a temperature sender, fittings, cable ties and instruction
sheet. This kit provides for the use of a coastal flush and a temperature sender at
the same time.
WATER TEMPERATURE SENDERS Fits Mercury/Mariner 75‑125 hp. (1993 and newer) 2 cycle outboards. Primarily
designed for adding to a Saltwater model which comes with the coastal flush as
Water temperature senders used for operation of a temperature gauge. standard equipment.
ADAPTER HARNESS
WATER TEMPERATURE SENDER

84- 11149A55
13536A13 Allows water temperature gauge hook‑up to the 225 EFI FourStroke outboard.
A two wire temperature sender for use on V‑6 outboard product. Furnished WATER TEMPERATURE SENDER
standard on engine powerhead, the fiche card specific to the application should be
used to verify correct use.
WATER TEMPERATURE SENDER

QUICKSILVER® RIGGING Used for temperature gauge
15995
Fits MCM 3.7L engines
ENGINE WATER TEMPERATURE SENDER

13536A14
A four wire temperature sender for use on V‑6 outboard product. Furnished 49734
standard on engine powerhead, the fiche card specific to the application should be
used to verify correct use. For dual station installations, used for temperature gauge
Fits MCM/MIE engines
WATER TEMPERATURE SENDER

12415
(1/8"‑27 NPT threads)
Fits outboard applications.
192
