ACCESSORY KITS FOR PLUS-SERIES ENGINES

ADAPTER - NON DTS 10 PIN TO 14 PIN 84-896537K24
25 ft. harness (896537A24) with new 14 pin connector for the engine and
additional connectors that allow easy quick connect solutions to the rigging
process. Included in this kit is also the new 3 position water‑proof high quality
keyswitch. (897716)
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors

ANALOG GAGE ADAPTER HARNESSES
HARNESS - NON DTS 14 PIN- ANALOG GAUGE

84-892444T02
Adapter that allows you to connect engines that have the older 10 pin engine
harness to the newer 14 pin helm harness
MCM/MIE engines that have the 10 pin engine harness.
ADAPTER-NON DTS 10 PIN TO 14 PIN W/SMARTCRAFT
CAN DATA

84-892990T01
This harness will connect directly to the non DTS harness at the helm. It will allow
you to connect to analog gauges on the dash and allows the choke function to work
on the 8/9.9/15/20 FourStroke carbureted outboards with serial numbers beginning
with "0R". 5 ft long Used with 84‑896537__ harness
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
84-892990T10
This harness will connect directly to the non DTS harness at the helm. It will allow
84-8M0153356 you to connect to analog gauges on the dash. 10 ft long Used with 84‑896537__
Adapter allows connection of 10‑pin engine harness to a 14‑pin boat harness when harness
using SmartCraft gauges. This adapter includes a 10‑pin CAN output to drive 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
SmartCraft gauges using the 14‑pin boat harness without having to install a blue All MCM / MIE engines equiped with 14 pin connectors
CAN data harness. A termination resistor 859318T1 is required, and may be
ordered separately. This is required for Quicksilver and Mercury Remanufacturing 84-892990T15
Plus Series 10‑pin engines when installed in boats using SmartCraft gauges that This harness will connect directly to the non DTS harness at the helm. It will allow
use a 14‑pin boat harness. you to connect to analog gauges on the dash. 15 ft long Used with 84‑896537__
harness
14-PIN BOAT HARNESSES W/KEY SWITCH 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors
KEY SWITCH W/ HARNESS - NON DTS 14 PIN SMARTCRAFT RIGGING

CAN DATA HARNESS - 10 PIN NON DTS WITH
RESISTORS (BLUE)

84-896537K02
2 ft. harness (896537A02) with new 14 pin connector for the engine and additional
connectors that allow easy quick connect solutions to the rigging process. Included
in this kit is also the new 3 position water‑proof high quality keyswitch. (897716)
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors 84-879982T20
All MCM / MIE engines equiped with 14 pin connectors 20 ft. (6.1 meter) SmartCraft data harness with (2) termination resistors
84-896537K20 Includes connections for horn and link gauge. Provides data link between
20 ft. harness (896537A20) with new 14 pin connector for the engine and SmartCraft CAN P Components.
additional connectors that allow easy quick connect solutions to the rigging
84-879982T25
QUICKSILVER® REPOWER 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors Includes connections for horn and link gauge. Provides data link between
process. Included in this kit is also the new 3 position water‑proof high quality
25 ft. (7.6 meter) SmartCraft data harness with (2) termination resistors
keyswitch. (897716)
SmartCraft CAN P Components.
All MCM / MIE engines equiped with 14 pin connectors
84-879982T30
30 ft. (9.1 meter) SmartCraft data harness with (2) termination resistors
Includes connections for horn and link gauge. Provides data link between
SmartCraft CAN P Components.
