Page 718 - Quicksilver Product Guide (2020) - 8M0163242

ELECTRICAL SYSTEM

Model CID/ #Cyl Year Range Serial # Range Alternator Starter Motor Slave Starter - Remote Mount
800 SC 572/ V-8 1993 - 1998 0D763836 and up - 50-808011A05(20) 89-818999A 2
(1) 12-3/4 in. (324 mm) diameter flywheel
(2) 14 in. (356 mm) diameter flywheel
(3) 37 amp
(4) 55 amp
(5) Black
(6) Blue
(7) Bravo Drive
(8) Firepower ignition
(9) Ignition module mounted on distributor
(10) Ignition module mounted on elbow
(11) LH - Standard rotation
(13) PG260 [9-1/4 in. (235 mm) long]
(14) PG260G [8-1/2 in. (216 mm) long]
(15) RH - Opposite rotation
(16) Standard ignition
(17) Thunderbolt ignition
(18) Thunderbolt IV
(19) Thunderbolt V
(20) Transmission or driveline models MERCURY® MERCRUISER®
(21) Delco alternator (65 amp)
(22) Mando alternator
(23) Alternate charging system converting to a conventional alternator system
(24) Relay assembly

ALTERNATOR REPAIR PARTS CONDENSER
BRUSH

811879
For Mando alternator
811884 DIODE RECTIFIER
For Mando alternator
CONDENSER

809162
For Mando alternator
809161
For Mando alternator
Priced individually, sold @ multiples of 2

Quicksilver Product Guide 709
