ELECTRICAL SYSTEM

Mercury Alternator P/N Mfg Mfg P/N Brush & Holder Condenser Diode Rectifier Diode Trio Negative Diode Positive Heat Slip Ring Voltage
Pack Heat Sink Sink Regulator
92497A 2 Motorola (3) 8MR2039F N.L.A. N/A N.L.A. N.L.A. N.L.A. N.L.A. N.L.A. N.L.A.
92497A 3 Motorola (3) 8EM2003KA N.L.A. N/A N.L.A. N.L.A. N.L.A. N.L.A. N.L.A. N.L.A.

98555A 1 Mando AR-150-AA N.L.A. N.L.A. N/A N/A N.L.A. N.L.A. N/A 42785
805884T Mando - 811884 809161 809162 N/A N/A N/A N/A 811883T
807652T Mando - 811884 811879 N.L.A. N/A N/A N/A N/A 811883T
807653T Mando - 811884 809161 809162 N/A N/A N/A N/A 811883T
807653F 2 Mando - 811884 809161 809162 N/A N/A N/A N/A 811883T
817119 1 Mando AC155603 811884 811879 N.L.A. N/A N/A N/A N/A 811883T
817119A 1 Mando AC155603 811884 811879 N.L.A. N/A N/A N/A N/A 811883T
817119A 4 Mando AC155603 811884 811879 N.L.A. N/A N/A N/A N/A 811883T
(1) external voltage regulator
(2) internal voltage regulator
(3) 3 wire alternator
(4) v-belt
(5) serpentine belt
(6) 50 mm diameter pulley
(7) 63.5 mm diameter pulley MERCURY® MERCRUISER®

STARTER REPAIR PARTS STARTER SOLENOID

STARTER BRUSH SET

33261
For Delco Remy starter. See application chart for specific models.
33270 STARTER SOLENOID
For Delco Remy starter
STARTER SOLENOID

809463A 1
For MCM Delco Remy PG 260 series starter and found in numerous outboard
applications from the 75/90 (1.5L) through the 225 hp. DFI engines, 3.0L EFI
product and also the 200‑300 hp. Verado.
STARTER SOLENOID

13037
For Delco Remy starter. See application chart for specific models.

89-850408
For Delco Remy starter. See application chart for specific models.
