COOLING SYSTEM

Model CID/ #Cyl Year Range Serial # Range Thermostat Housing Thermostat Thermostat & Thermostat Gaskets Gaskets Gaskets
Cover Gasket Kit Required Required (2) Required (3)
8.2L Mag & HO 502/ V-8 2010 - 2019 1A350340 and up N/A N/A N/A 8M0045990 25-807134 1 N/A N/A
8.2L MIE & HO 502/ V-8 2010 - 2019 1A350802 and up N/A N/A N/A 8M0045990 25-807134 1 N/A N/A
8.2L MIE 502/ V-8 1990 - 1992 0C878221 - 0D857199 16413A 3(7)(12) 17494A 1 807252Q 4 8M0089715 25- 30224 27- 33179 2 27- 53045Q01
8.2L MIE, FWC 502/ V-8 1990 - 1992 0C878221 - 0D857199 55131A 5(6) N.L.A. 807252Q 4 8M0089715 27- 47510 27- 48818 1 27- 53045Q01
8.2L MIE 502/ V-8 1993 - 1996 0D857200 - 0F350274 16413A 3(7)(12) 17494A 1 807252Q 5 8M0109441 27- 53045Q01 27-806871 N/A
8.2L MIE 502/ V-8 1996 0F350275 - 0F819619 8M0061381(7) N/A 807252Q 5 8M0109441 27- 53045Q01 27-806871 N/A
8.2L MIE, FWC 502/ V-8 1993 - 1996 0D857200 - 0F819619 55131A 5(6) N/A 807252Q 5 8M0109441 27- 48818 1 27- 53045Q01 N/A
8.2L MPI MIE 502/ V-8 1996 - 2001 0F819620 - 0L674200 8M0061381(7) N/A 807252Q 5 8M0109441 27- 53045Q01 27-806871 N/A
8.2L MPI MIE, FWC 502/ V-8 1996 - 2001 0F819620 - 0L674200 861188A 1(6) 807075A 1 99155T 1 99155 1 25-807134 1 N/A N/A

500 Bulldog 540/ V-8 1990 - 2001 0C577254 - 0M050281 87290A 4 47441A 1 N/A 8M0089715 - 27- 47510 27- 53045Q01
575 540/ V-8 1986 - 1992 0A677429 - 0D763716 87290A 4 47441A 1 807252Q 3 8M0089715 27- 47510 27- 48818 1 27- 53045Q01
800 MCM 572/ V-8 1993 - 1996 0D763836 and up - N.L.A. N/A - - N/A N/A
(1) Design I
(2) Design II
MERCURY® MERCRUISER® (5) Cast Iron Exhaust Manifold
(3) Design III
(4) Aluminum Exhaust Manifold

(6) Closed Cooling
(7) Standard Cooling
(8) With check ball
(9) Without check balls
(10) SN 4167000 and up
(11) Original thermostat housing listed is NLA. Order update kit 87290A23.
(12) Original thermostat housing listed is NLA. Order update kit 90736A24.
(13) Complete thermostat housing update kit
(14) Single and 3 point drain system
(15) 7 point drain system
(16) Mechanical throttle body
(17) Digital throttle body
(18) Emission control engine
(19) Manual drain
(20) Air actuated drain

HOSES - WATER CIRCULATING PUMP HOSE
CIRCULATING PUMP HOSE

32-861590A05
Fits MCM/MIE GM V‑6 and V‑8 (305, 350 & 377 cid) engines
32-8M0071007
Fits MCM 120/2.5L, 140/3.0L & 160/165

786
