INTERNAL ENGINE

Model Cyl/CID/Litre Year Range Serial # Range New Longblock New P/N Status Reman Longblock P/N Cylinder Head
8.2L MIE (Gen V) 8.2L 502 CID V-8 1993 - 1996 0D857200 - 0F819619 807745A05 N.L.A. N.L.A. 938-8M0115141(15)
8.2L MIE MPI (Gen VI) (LH) 8.2L 502 CID V-8 1996 - 2001 0F819620 - 0L674200 807745A05 N.L.A. N.L.A. 938-8M0115141(15)
(1) 1 pc. Rear main seal
(2) 2 pc. Rear main seal
(5) Gen II w/o balance shaft
(6) Gen II w/balance shaft
(7) Flat Tappet & camshaft
(8) Roller Lifter & camshaft
(11) See MCM S.B. 86-22
(12) w/o crank position sensor
(13) See MerCruiser Service Bulletin 2007-11
(14) Order 805052R5
(15) Brand new fully assembled cylinder heads
(16) Reman fully assembled cylinder heads
(17) Will require replacing the original rocker arms with Rocer Arm & Ball kit p/n 824335T
MERCURY® MERCRUISER® (20) Reference MerCruiser Service Bulletin 2016-10
(18) Brand new bare cylinder heads
(19) Reference MerCruiser Service Bulletin 2017-08
(21) Non-roller rocker arm head
(22) Reference MerCruiser Service Bulletin 2018-01

PISTONS

PISTON PISTON

733-803850T
Standard size
Cast aluminum, Shaped dish head
733-889246A73 Fits MCM 140/3.0L (1989 and older)
Standard size 733- 3818 1
Cast aluminum
Fits MCM 100 Vazer .020 (.5mm) Oversize
Cast aluminum, Shaped dish head
PISTON Fits MCM 140/3.0L (1989 and older)
PISTON

736- 2343
Standard size 733-810852
Cast aluminum, Flat top with 4 valve reliefs
Fits MCM 120/2.5L & 190 (V‑8) Standard size
Cast aluminum, Flat Top
Fits MCM 3.0L/LX (1990 & newer)
733-810853T
.020 (.5mm) Oversize
Cast aluminum, Flat Top
Fits MCM 3.0L/LX (1990 & newer)
