INTERNAL ENGINE

PISTON PISTON

735-883515002 700-8M6001407
Standard size piston w/ rod Fits MCM/MIE 8.2L engines (2010 & newer)
Port
Includes piston rings PISTON
Fits MCM/MIE 496 Mag & 8.1S
PISTON

MERCURY® MERCRUISER® 700-8M6001408

Fits MCM/MIE 8.2L engines (2010 & newer)
735-881597002
.030 (.76 mm) Oversize .030 (.76mm) Oversize
Port
Note: Does not include piston rings
Fits MCM/MIE 496 Mag & 8.1S (s/n 0W020104 and below)
Fits MCM/MIE 496 Mag HO & 8.1S HO (s/n 0W020080 and below)

PISTON CHART

Pistons

Model CID/Litre Cyl. Year Range Serial # Range Piston - Std. Pistons .020 (.5 mm) O/S Pistons .030 (.76 mm) O/S
100 Vazer 98/1.6L I/L 4 2007 - 2009 1A035000 - 1A036006 733-889246A73 N/A N/A

120 153/2.5L I/L 4 1964 - 1986 1666601 - 0B531853 736- 2343 N/A N.L.A.
2.5L 153/2.5L I/L 4 1987 - 1989 0B531854 - OC853255 736- 2343 N/A N.L.A.
140 181/3.0L I/L 4 1968 - 1986 2508261 - 0B450800 733-803850T 733- 3818 1 N/A
3.0L 181/3.0L I/L 4 1987 - 1989 0B450801 - 0C856558 733-803850T 733- 3818 1 N/A
3.0L 181/3.0L I/L 4 1990 - 1994 0C856559 - 0F603999 733-810852 733-810853T N/A
3.0L 181/3.0L I/L 4 1998 - 2019 0L010042 and up 733-810852 733-810853T N/A
3.0L MPI 181/3.0L I/L 4 2008 - 2019 1A072812 and up 733-810852 733-810853T N/A
3.0LX 181/3.0L I/L 4 1990 - 1997 0C856559 - 0K999999 733-810852 733-810853T N/A

165/3.7L 224/3.7L I/L 4 1987 - 1989 0B434941 - 0C762299 N.L.A. N.L.A.(11) N.L.A.
170 224/3.7L I/L 4 1985 - 1986 6916779 - 0B434940 N.L.A. N.L.A.(11) N.L.A.
180/3.7LX 224/3.7L I/L 4 1987 - 1989 0B436391 - 0C762299 N.L.A. N.L.A.(11) N.L.A.
190 (3.7L) 224/3.7L I/L 4 1985 - 1986 6916779 - 0B436390 N.L.A. N.L.A.(11) N.L.A.
470 224/3.7L I/L 4 1976 - 1984 4208730 - 6916778 N.L.A. N.L.A.(11) N.L.A.
485 224/3.7L I/L 4 1980 - 1982 5685394 - 6218036 N.L.A. N.L.A.(11) N.L.A.
488 224/3.7L I/L 4 1983 - 1984 6170297 - 6916778 N.L.A. N.L.A.(11) N.L.A.
