INTERNAL ENGINE

Model CID/ # Cyl Year Range Serial # Range 1 Cylinder Ring 1 Cylinder Ring Kit 1 Cylinder Ring Kit Complete Engine Complete Engine Complete Engine
Kit - Std. - .020 (.5 mm) O/S - .030 (.76 mm) O/S Ring Set - Std. Ring Set - .020 (.5 Ring Set - .030 (.76
mm) O/S mm) O/S
8.1S MPI MIE & HO 496/ V-8 2001 - 2019 0M026000 and up 39-881601 N/A 39-881602 N/A N/A N/A

465 502/ V-8 1990 0C849992 - 0C850209 N/A N/A N/A - N/A -
465 502/ V-8 1990 - 1992 0C850210 - 0D725646 39-827660T N/A N.L.A.(4) N/A N/A N/A
465 (Gen V) 502/ V-8 1992 - 1994 0D725647 - 0F213244 39-827660T N/A N.L.A.(4) N/A N/A N/A
500 (Gen V) 502/ V-8 1994 - 1996 0F213293 - 0F745159 39-827660T N/A N.L.A.(4) N/A N/A N/A
500 (Gen VI) 502/ V-8 1997 0K745195 - 0L001772 39-827660T N/A N.L.A.(4) N/A N/A N/A
500 EFI 502/ V-8 1999 - 2005 0L001477 - 0M907127 39-827660T N/A N.L.A. N/A N/A N/A
502 Mag Bravo 502/ V-8 1990 - 1992 0C878221 - 0D824588 39-827660T N/A N.L.A.(4) N/A N/A N/A
502 Mag Bravo (Gen V) 502/ V-8 1992 - 1993 0D824589 - 0F114528 39-827660T N/A N.L.A.(4) N/A N/A N/A
502 Mag EFI 502/ V-8 1993 - 1996 0D840650 - 0F802599 39-827660T N/A N.L.A.(4) N/A N/A N/A
502 Mag MPI (Gen VI) 502/ V-8 1996 - 1997 0F802600 - 0K999999 39-827660T N/A N.L.A.(4) N/A N/A N/A
502 Mag MPI (Gen VI) 502/ V-8 1998 - 2001 0L017000 - 0M024999 39-827660T N/A N.L.A. N/A N/A N/A
525 EFI 502/ V-8 2003 - 2019 0M900146 and up 39-827660T N/A N.L.A. N/A N/A N/A
575 SCi 502/ V-8 2001 - 2005 0M900146 - 0M950526 39-827660T N/A N.L.A. N/A N/A N/A
600 SC 502/ V-8 1991 - 1992 0D456489 - 0D456768 N/A N/A N/A - N/A -
600 SC (Gen V) 502/ V-8 1992 - 1996 0D725676 - 0F877642 N/A N/A N/A - N/A -
600 SC (Gen VI) 502/ V-8 1997 - 2000 0K000227 - 0L601186 N/A N/A N/A - N/A -
8.2L Mag 502/ V-8 2010 - 2019 1A340350 and up 39-8M6001037 N/A 39-8M6001026 N/A N/A N/A MERCURY® MERCRUISER®
8.2L MIE 502/ V-8 2010 - 2019 1A340802 and up 39-8M6001037 N/A 39-8M6001026 N/A N/A N/A
8.2L MIE w/Hurth 502/ V-8 1990 - 1992 0C878221 - 0D857199 39-827660T N/A N.L.A.(4) N/A N/A N/A
8.2L MIE (Gen V) 502/ V-8 1993 - 1995 0D857200 - 0F819619 39-827660T N/A N.L.A.(4) N/A N/A N/A
8.2L MPI MIE LH (Gen VI) 502/ V-8 1996 - 1997 0F819620 - 0K999999 39-827660T N/A N.L.A.(4) N/A N/A N/A
8.2L MPI MIE LH (Gen VI) 502/ V-8 1998 - 2001 0L002450 - 0L674200 39-827660T N/A N.L.A. N/A N/A N/A

500 Bulldog 540/ V-8 1990 - 1996 0C577254 - 0F745405 N/A N/A N/A - N/A -
500 Bulldog 540/ V-8 1997 - 2001 0K000248 - 0M050281 N/A N/A N/A - N/A -
575 540/ V-8 1986 - 1992 0A677429 - 0D763716 N/A N/A N/A - N/A -
800 SC (Gen V) 572/ V-8 1993 - 1998 0D763836 and up N/A N/A N/A - N/A N.L.A.
(1) For .190 to .220 Oil Ring Groove Depth (See MCM P.B. 98-2)
(2) For .167 Oil Ring Groove Depth (See MCM P.B. 98-2)
(3) Use with 3ZC GM Engine Code
(4) Piston/Ring Kit
(5) .035 (.89 mm) O/S
(6) .005 (.125 mm) O/S
(7) .010 (.25 mm) Oversize

BEARINGS - CONNECTING ROD CON ROD BEARING

CON ROD BEARING

23-804982
Standard size
Fits MCM 3.0L (s/n 0L605542 and up)
23- 85677
Standard size 23-804982001
Fits MCM 120/2.5L & 160/165 (6 cyl), 190 & 225 (GM V8) .001 (.25 mm) Undersize
Fits MCM 3.0L (s/n 0L605542 and up)
