         Mercury 7.6L V12 600hp Verado  & 500hp SeaPro  Outboards                         Serial Number 3B060051 and Up
           CONTROLS & RIGGING


          MISCELLANEOUS ACCESSORIES (continued)

          Rig Tube Flange Housing      Pairs with the 2.5” rig tube on the engine side to provide a secure connection point  8M0180071
                                       Clean Power Harness, 3ft                                            8M0150521
                                       Clean Power Harness, 6ft                                            8M0150522
                                       Clean Power Harness, 10ft                                           899887T13
          Clean Power Harness
                                       Clean Power Harness, 15ft                                           8M0150523
                                       Clean Power Harness, 20ft                                           899887T14
                                       Clean Power Harness, 25ft                                           8M0150524
          Fuel Level Sender Harness    10ft - Fuel level sender harness                                    898289T75
          Fuel Level Sender Harness    20ft - Fuel level sender harness                                    898289T76
          Rig Center                   Rig center for use on V12 engines (need one per engine)             8M0168337
                                       Provides connection for fuel relay, fuel level. Remote trim pad and MerCathode. Rig Center   8M0173598
                                       OEM breakout harness (gray)
          Rig Center OEM Breakout Harnesses
                                       Provides connection for fuel relay, fuel level. Remote trim pad and MerCathode. Rig Center   8M0173596
                                       Mercury breakout harness (black)
          Umbilical Harness, 10ft      Umbilical harness for use with rig center, 10ft                     8M0171475
          Umbilical Harness, 15ft      Umbilical harness for use with rig center, 15ft                     8M0171476
          Umbilical Harness, 20ft      Umbilical harness for use with rig center, 20ft                     8M0171477
          Umbilical Harness, 25ft      Umbilical harness for use with rig center, 25ft                     8M0179757
                                       Single engine SmartCraft/DTS                                        8M6007933
                                       Dual engine SmartCraft/DTS                                          8M6007934
                                       Triple engine SmartCraft/DTS                                        8M6007937
                                       4/5/6 engine SmartCraft/DTS                                         8M6007938
          1st Mate TM                  Mercury captain fob kit                                             8M6007943
                                       Mercury passenger fob kit                                           8M6007944
                                       Wearables accessories - black                                       8M6007946
                                       Wearables accessories - blue                                        8M6007932
                                       Wearables accessories - red                                         8M6007945
          MP Alert                     MP Alert system SmartCraft                                          8M0109507
          ROKK TM                      Charge+ waterproof dual USB power (12-24 VDC)                       8M6005670
          TRANSOM MOUNTED TRIM PADS
          Adapter Harness              Adapter harness for triple and quad engine configurations           8M0175106
          Adapter Harness              Adapter harness for single and dual engine configurations           8M0175109
                                       Extension Harness, 10ft                                             8M0054183
                                       Extension Harness, 20ft                                             8M0054185
          Extension Harness
                                       Extension Harness, 30ft                                             8M0054186
                                       Extension Harness, 50ft                                             8M0054187
                                       Trim pad for dual engine configuration                              879303A02
          Trim Pads                    Trim pad for triple engine configuration                            879303A03
                                       Trim pad for quad engine configuration                              879303A04
          Fuel Control Solenoid Relay  Connects to rig center to control boat mounted fuel demand electrical valve  8M0153455





                                                                          Parts & Accessories / 800-MERCURY
