Page 8 - V12 Accessories Guide

®
TM
Mercury 7.6L V12 600hp Verado & 500hp SeaPro Outboards Serial Number 3B060051 and Up
SERVICE PARTS & ACCESSORIES

TRANSOM BOLTS (continued)

8.5” Transom Bolt Kit - 5/8 Quantity (1) 8M0171832

8.5” Transom Bolt Kit - 5/8 Quantity (6) 8M0171833
9.5” Transom Bolt Kit - 5/8 Quantity (1) 8M0171834
9.5” Transom Bolt Kit - 5/8 Quantity (6) 8M0171835

10.5” Transom Bolt Kit - 5/8 Quantity (1) 8M0171836
10.5” Transom Bolt Kit - 5/8 Quantity (6) 8M0171837

12.5” Transom Bolt Kit - 5/8 Quantity (1) 8M0176953
12.5” Transom Bolt Kit - 5/8 Quantity (6) 8M0176954

PROPELLERS

Propeller Part Number Propeller Model Pitch Location Rotation # of Blades

8M0166979 Verado12 23 Front LH 4
8M0166980 Verado12 23 Rear RH 3

8M0166981 Verado12 24.5 Front LH 4
8M0166982 Verado12 24.5 Rear RH 3

8M0166983 Verado12 26 Front LH 4
8M0166984 Verado12 26 Rear RH 3

8M0166985 Verado12 27.5 Front LH 4
8M0166986 Verado12 27.5 Rear RH 3
8M0166987 Verado12 29 Front LH 4

8M0166988 Verado12 29 Rear RH 3
8M0166989 Verado12 31 Front LH 4

8M0166990 Verado12 31 Rear RH 3
8M0166991 Verado12 33 Front LH 4
8M0166992 Verado12 33 Rear RH 3

8M0166993 Verado12 35 Front LH 4
8M0166994 Verado12 35 Rear RH 3

8M0166995 Verado12 37 Front LH 4
8M0166996 Verado12 37 Rear RH 3

Parts & Accessories / 800-MERCURY
