MERCURY RACING PROPELLER CHARTS

Diameter Pitch Lab Finished LH Lab Finished RH MAX 5 ST Lab Finished Propeller Chart
Rotation Rotation
15 29.5 48-8M0118003 48-8M0118002 Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation
15 29 48-8M0118001 48-8M0118000
15 28.8 48-8M0131159 48-8M0131158 15.25 22.5 48-8M0156495 48-8M0156494
15.25 23 48-8M0156497 48-8M0156496
15 28.3 48-8M0131157 48-8M0131156
15 28 48-8M0117999 48-8M0117998 15.25 23.5 48-8M0156499 48-8M0156498
15.25 24 48-8M0156501 48-8M0156500
15 27.5 48-8M0117997 48-8M0117996
15 27 48-8M0117995 48-8M0117994 15.25 24.5 48-8M0156505 48-8M0156504
15 26.8 48-8M0131155 48-8M0131154 15.25 25 48-8M0156507 48-8M0156506
15 26.3 48-8M0131153 48-8M0131152 15.25 25.5 48-8M0156509 48-8M0156508
15 26 48-8M0117993 48-8M0117992 15.25 26 48-8M0156511 48-8M0156510
15.25 26.5 48-8M0156515 48-8M0156514
15 25.5 48-8M0117991 48-8M0117990
15 25 48-8M0117989 48-8M0117988 15.25 27 48-8M0156517 48-8M0156516
15.25 27.5 48-8M0156519 48-8M0156518
15 24.8 48-8M0131151 48-8M0131150
15 24.3 48-8M0131149 48-8M0131148 15.25 28 48-8M0156521 48-8M0156520
15 24 48-8M0117987 48-8M0117986 15.25 28.5 48-8M0156525 48-8M0156524
15 23.5 48-8M0117985 48-8M0117984 15.25 29 48-8M0156527 48-8M0156526
15 23 48-8M0117983 48-8M0117982 15.25 29.5 48-8M0156529 48-8M0156528
15 22.8 48-8M0131147 48-8M0131146 15.25 30 48-8M0156531 48-8M0156530
15 22.3 48-8M0131145 48-8M0131144 15.25 30.5 48-8M0156535 48-8M0156534
15.25 31 48-8M0156537 48-8M0156536
15.25 22.5 48-8M0156439 48-8M0156434
15.25 23 48-8M0156437 48-8M0156436 15.25 31.5 48-8M0156539 48-8M0156538
15.25 32 48-8M0156541 48-8M0156540
15.25 24 48-8M0156441 48-8M0156440
15.25 24.5 48-8M0156445 48-8M0156444 15.25 32.5 48-8M0156545 48-8M0156544
15.25 25 48-8M0156447 48-8M0156446 15.25 33 48-8M0156547 48-8M0156546
15.25 25.5 48-8M0156449 48-8M0156448 15.25 33.5 48-8M0156549 48-8M0156548
15.25 26 48-8M0156451 48-8M0156450 15.25 34 48-8M0156551 48-8M0156550
15.25 26.5 48-8M0156455 48-8M0156451
15.25 27 48-8M0156457 48-8M0156456 MAXIMUS LONG TUBE 5 BLADE SS LAB FINISHED
15.25 27.5 48-8M0156459 48-8M0156458
15.25 28 48-8M0156461 48-8M0156460
15.25 28.5 48-8M0156465 48-8M0156464
15.25 29 48-8M0156467 48-8M0156466
15.25 29.5 48-8M0156469 48-8M0156468
15.25 30 48-8M0156471 48-8M0156470
15.25 30.5 48-8M0156475 48-8M0156474
15.25 31 48-8M0156477 48-8M0156476
15.25 31.5 48-8M0156479 48-8M0156478
Maximus Long Tube 5 Blade Stainless Steel Sterndrive
15.25 32 48-8M0156481 48-8M0156480
15.25 32.5 48-8M0156485 48-8M0156484 Propeller Chart
15.25 33 48-8M0156487 48-8M0156486
Diameter Pitch Lab Finished LH Lab Finished RH
15.25 33.5 48-8M0156489 48-8M0156488 Rotation Rotation
15.25 34 48-8M0156491 48-8M0156490 15.63 23 48-889975L45 48-889974L45
15.3 23 48-889975L44 48-889974L44
MAX 5 ST LAB FINISHED PROPELLER 15.63 24 48-889975L65 48-889974L65
15.3 24 48-889975L64 48-889974L64
15 24 48-889975L63 48-889974L63
15.63 25 48-889965L45 48-889964L45
15.3 25 48-889965L44 48-889964L44
15.63 26 48-889965L65 48-889964L65
15.3 26 48-889965L64 48-889964L64
15 26 48-889965L63 48-889964L63
15.63 27 48-889967L45 48-889966L45
15.3 27 48-889967L44 48-889966L44
15.63 28 48-889967L65 48-889966L65
15.3 28 48-889967L64 48-889966L64
15 28 48-889967L63 48-889966L63

2021 Mercury Propeller Guide 87
