Page 839 - LATIN AMERICA ACCESSORIES GUIDE (2019) English
P. 839
MERCURY RACING PROPELLER TYPE
48-842942L70 CNC CLEAVER 5 BLADE 15 DEGREE RAKE LAB
15 x 23 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-8M0073458 FINISHED
16 x 22 Pitch LH SS 4 BL High Gloss ‑ Front
48-8M0073459 600 HP, 900 HP, 1200 HP and 1550 HP
15 x 22 Pitch RH SS 3 BL High Gloss ‑ Rear 822974 Six and 8M drive bushing
822975 Retaining ring
48-8M0125741 11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
16 x 21.5 Pitch LH, SS 4 BL High Gloss ‑ Forward for SSM Six and M8
48-8M0125740 For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
15 x 21.5 Pitch RH, SS 3 BL High Gloss ‑ Rear 8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
48-842939L70 Finish propellers have a 26 Spline hub with 1.75/1.88 inch
(44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length. The
16 x 21 Pitch LH SS 4 BL High Gloss ‑ Front 15 degree rake propellers are designed specifically for step Vee hulls,
48-842940L70 diameters from 15 inch to 18 inch and pitch from 26 inch to 40 inch
15 x 21 Pitch RH SS 3 BL High Gloss ‑ Rear (custom order 41 and 42 inch pitch,14.5" diameters and limited 13
48-8M0125739 degree rake available ‑ contact Mercury Racing).
16 x 20 Pitch LH, SS 4 BL Hogh Gloss ‑ Forward If moving from the old style 5 blade Cleaver to the new style 5 blade
CNC Cleaver generally move up 2 inch of pitch; example if old style was
48-8M0125738 17 x 33 move to 17 x 35 CNC Cleaver.
15 x 20 Pitch RH, SS 3 BL High Gloss ‑ Rear
As a general rule for every 1 inch of pitch change, the effect will typically
be 150 RPM change. For every .50 inch of diameter change, the effect
will typically be 150 RPM change.
For a complete listing of part numbers see Mercury Racing Propeller
chart section. MERCURY RACING PROPELLER TYPE
CNC CLEAVER 5 BLADE 18 DEGREE RAKE LAB
FINISHED
600 HP, 900 HP, 1200 HP and 1550 HP
822974 Six and 8M drive bushing
822975 Retaining ring
11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
for SSM Six and M8
For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
Finish propellers have a 26 Spline hub with 1.75/1.88 inch
(44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length.
Custom order 41 and 42 inch pitch available contact Mercury Racing.
For a complete listing of part numbers see Mercury Racing Propeller
chart section.
CNC CLEAVER 5 BLADE 21 DEGREE RAKE LAB
FINISHED
600 HP, 900 HP, 1200 HP and 1550 HP
822974 Six and 8M drive bushing
822975 Retaining ring
11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
for SSM Six and M8
For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
Finish propellers have a 26 Spline hub with 1.75/1.88 inch
(44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length.
Custom order 41 and 42 inch pitch available contact Mercury Racing.
For a complete listing of part numbers see Mercury Racing Propeller
chart section.
2019 Mercury Precision Parts & Accessories Guide 829
