Page 235 - Canada Parts Guide (2021) - 8M0174475

MERCURY® MERCRUISER® DRIVE SYSTEMS

Model Gear Ratio Year Range Serial # Range Drive Gear Driven Gear/ Gear Kit Upper Gear Repair Kit
Bravo III - Diesel 1.50 1996 - 1999 0F730000 - 0M100000 N.S.S. 43-883473A 3 N/A
Bravo III - Diesel 1.36 1996 - 1999 0F730000 - 0M100000 N.S.S. 43-883476A 3 N/A
Bravo III X 2.43 2000 - 2021 0M100001 and up N.S.S. 43-887909A 1 N/A
Bravo III X 2.20 2000 - 2021 0M100001 and up N.S.S. 43-887909A 1 N/A
Bravo III X 2.00 2000 - 2021 0M100001 and up N.S.S. 43-887903A 1 N/A
Bravo III X 1.81 2000 - 2021 0M100001 and up N.S.S. 43-887906A 1 N/A
Bravo III X 1.65 2000 - 2021 0M100001 and up N.S.S. 43-887903A 1 N/A
Bravo III X 1.50 2000 - 2021 0M100001 and up N.S.S. 43-887903A 1 N/A
Bravo III X 1.36 2000 - 2021 0M100001 and up N.S.S. 43-887906A 1 N/A
Blackhawk 1.65 1994 0F186717 - 0F392505 N.L.A.(2) 43-883479A 4 N/A
Blackhawk 1.65 1994 - 2021 0F392506 and up N.L.A.(5) 43-883473A 4 N/A
Blackhawk 1.50 1994 - 2021 0F186717 and up N.L.A.(5) 43-883473A 4 N/A
Blackhawk 1.36 1994 - 2021 0F186717 and up N.L.A.(6) 43-883476A 4 N/A
III 1.50 1968 - 1972 2373127 - 3002613 N.S.S. N.L.A. N/A
III 2.00 1968 - 1972 2373127 - 3002613 N.S.S. N.L.A. N/A
TR/TRS 1973 - 1993 3377316 and up N.L.A. N.L.A. N/A
MERCURY® MERCRUISER® (3) Order gear kit 43-883479A 3
(1) Some early 1.5 units with cone 89449 & cup 89410 must order an additional bearing 31-35990A 1
(2) Order gear kit 43-883479A 4
(4) Order gear kit 43-883473A 4
(5) Order gear kit 43-883473A 3
(6) Order gear kit 43-883476A 4
(7) Order gear kit 43-883476A 3

SEAL KITS - DRIVESHAFT HOUSING SEAL KIT

SEAL KIT

26- 16709A 2
Driveshaft Hsg
Fits Bravo I, II, III, X, XR & XZ
26- 32511A 1
Fits I, IA/IB/IC, MC‑I, R, MR & Alpha One (1964‑1990) SEAL & BEARING KITS - GEAR HOUSING
SEAL KIT
SEAL & BEARING KIT

26- 88397A 1
Driveshaft Hsg 31-803068T 1
Fits Alpha One Gen II (1991 & newer) Fits R drive

226 Telephone Order and Assistance, (905) 636-4749; Fax (800) 217-6517
