Page 250 - Canada Parts Guide (2021) - 8M0174475

MERCURY® MERCRUISER® POWER TRIM

Model Year Range Serial # Range Anchor Pin - Front Anchor Pin - Rear Front Anchor Pin Kit Rear Anchor Pin Kit Trim Cylinder
Bushings
II (1.78) 1968 - 1969 2398798 - 2671321 N.L.A. N/A N/A N.L.A. 23- 90203
III 1968 - 1972 2373127 - 3002613 N/A N/A N.L.A. N.L.A. 23- 90203
215E/H 1970 - 1972 2782203 - 2915034 N/A N/A N.L.A. N.L.A. 23- 90203
TR/TRS 1973 - 1993 3377316 and up N/A N/A N.L.A. N.L.A. 23- 90203

POWER TRIM CYLINDER HOSES POWER TRIM HOSE

POWER TRIM HOSE

32- 45973
Trim cylinder to connector block
Starboard ‑ up pressure
32- 45703
Trim cylinder to connector block POWER TRIM HOSE
Port ‑ down pressure MERCURY® MERCRUISER®
Fits 120, 140 & 160 drives
POWER TRIM HOSE

32- 86036Q
A UV radiation resistant stainless steel braided power trim hose.
Port & starboard ‑ up and down pressures.
Fits MC‑I drive (s/n 6225576 and below), and MC II, III, 215 E/H, TR and TRS
32- 45974 drives.
Trim cylinder to connector block Quicksilver Branded, Peg Display Product Point of Sale Packaged.
Port ‑ up pressure
Fits 120, 140 & 160 drives POWER TRIM HOSE
POWER TRIM HOSE

32- 87234
Trim cylinder to connector block, use w/ cylinders requiring external trim lines
32- 69871 Port ‑ down pressure
Trim cylinder to connector block Fits MC‑I drive (s/n 6225576 and below)
Starboard ‑ down pressure
Fits 120, 140 & 160 drives

2021 Mercury Precision Parts Guide 241
