Page 126 - Toro Irrigation Product Catalogue August 2020

Aqua-Traxx Premium Drip Tape - with the PBX advantage cont.
®

AQUA-TRAXX Flow Rates
®
Outlet Emitter Flow Rate Filtration Requirement
Flow
Emitter
Emitter Flow Part Number Spacing gph @ 8 psi lph @ 55 Kpa gpm/100ft lph/1 meter Exponent Mesh Micron Classification
cm @ 8 psi @ 55 kpa
0.07 GPH AAXxx0817 20 0.07 0.26 0.17 1.30 0.55 200 74 Low
AAXxx1609 40 0.07 0.26 0.09 0.65 0.55 200 74 Low
0.09 GPH AAXxx0822 20 0.09 0.34 0.22 1.66 0.55 200 74 Low
AAXxx1611 40 0.09 0.34 0.11 0.83 0.55 200 74 Low
0.10 GPH AAXxx0825 20 0.10 0.38 0.25 1.86 0.55 200 74 Low
AAXxx1613 40 0.10 0.38 0.13 0.93 0.55 200 74 Low
0.13 GPH AAXxx0467 10 0.13 0.51 0.67 4.99 0.5 140 105 Low
AAXxx0644 15 0.13 0.51 0.44 3.33 0.5 140 105 Low
AAXxx0834 20 0.13 0.51 0.34 2.50 0.5 140 105 Low
AAXxx1222 30 0.13 0.51 0.22 1.66 0.5 140 105 Low
AAXxx1617 40 0.13 0.51 0.17 1.25 0.5 140 105 Low
AAXxx1814 45 0.13 0.51 0.14 1.11 0.5 140 105 Low
AAXxx2411 60 0.13 0.51 0.11 0.83 0.5 140 105 Low
0.15 GPH AAXxx0650 15 0.15 0.57 0.50 3.73 0.5 140 105 Low
AAXxx1225 30 0.15 0.57 0.25 1.86 0.5 140 105 Low
AAXxx1817 45 0.15 0.57 0.17 1.24 0.5 140 105 Low
0.165 GPH AAXxx1034 25 0.16 0.62 0.34 2.50 0.5 140 105 Low
0.20 GPH AAXxx04100 10 0.20 0.76 1.00 7.47 0.5 140 105 Med
AAXxx0667 15 0.20 0.76 0.67 4.99 0.5 140 105 Med
AAXxx0850 20 0.20 0.76 0.50 3.74 0.5 140 105 Med
AAXxx1234 30 0.20 0.76 0.34 2.50 0.5 140 105 Med
AAXxx1625 40 0.20 0.76 0.25 1.87 0.5 140 105 Med
AAXxx1822 45 0.20 0.76 0.22 1.67 0.5 140 105 Med
AAXxx2417 60 0.20 0.76 0.17 1.25 0.5 140 105 Med
0.27 GPH AAXxx04134 10 0.27 1.01 1.34 9.99 0.5 140 105 Med
AAXxx0690 15 0.27 1.01 0.90 6.66 0.5 140 105 Med
AAXxx0867 20 0.27 1.01 0.67 4.99 0.5 140 105 Med
AAXxx1245 30 0.27 1.01 0.45 3.33 0.5 140 105 Med
AAXxx1634 40 0.27 1.01 0.34 2.50 0.5 140 105 Med
AAXxx1830 45 0.27 1.01 0.30 2.22 0.5 140 105 Med
AAXxx2422 60 0.27 1.01 0.22 1.67 0.5 140 105 Med
0.34 GPH AAXxx04168 10 0.34 1.27 1.68 12.48 0.5 140 105 High
AAXxx06112 15 0.34 1.27 1.12 8.33 0.5 140 105 High
AAXxx0884 20 0.34 1.27 0.84 6.24 0.5 140 105 High
AAXxx1069 25 0.34 1.29 0.69 5.06 0.5 140 105 High
AAXxx1256 30 0.34 1.27 0.56 4.16 0.5 140 105 High
AAXxx1642 40 0.34 1.27 0.42 3.12 0.5 140 105 High
AAXxx1838 45 0.34 1.27 0.38 2.78 0.5 140 105 High
AAXxx2428 60 0.34 1.27 0.28 2.08 0.5 140 105 High
Note: not all configurations are available at time of print. Consult your local Toro Territory Manager to confirm local availability.

Product Code Definition
Emitter Flow
AA5100867-600 Classification @ 55 kPa
Low 0.26 - 0.57 Lph

Med 0.76 - 1.01 Lph
Aqua-Traxx Tube Diameter Wall thickness Emitter Flow Rate Roll Length High 1.27 - 2.01 Lph
®
with the PBX (5/8” - 16mm) (10 Mil) Spacing (0.67 Gph x 10’ (6000’)
Advantage (08” - 20 cm) per 100’)
Wall Thickness
Key: Part number AA51000867-600
AA = Aqua-Traxx with the PBX Advantage *denotes: 5 0.127
®
5 = Tube Diameter (5/8”) - X-5 for 5/8”, 7 for 7/8” 6 0.152
10 = Wall thickness (10 mil) and 9 for 1-1/8”
08 = Emitter spacing (08” or 20 cm) - XX-for mil (1/1000 of an inch) 8 0.203
th
67 = Flow per 100’ of Tape ( .67 Gph per 100’) thickness 10 0.254
600 = Roll length (x 10’)
12 0.305
Metric outlet spacing expressed in nominal length
Gph and gpm represent US gallons mil is the unit of 1/1000 of
Coefficient of Variation (CV) less than 3% an inch
†Maximum pressure within laterals while operating or flushing

Company policy is one of constant improvement and therefore changes in specifications may
116 be made without notice and without incurring liability. Please refer to www.toro.com.au
