Results: CHAPTER 4
Table 4.5

Number of Speed of Number of turns Maximum reading of galvanometer Electromagnetism
magnets magnet of solenoid First attempt Second attempt Average

KEMENTERIAN PENDIDIKAN MALAYSIA
One Slow 400
One Fast 400
One Slow 800

Two Slow 800

Discussion:
1. Why does the galvanometer pointer deflect when a magnet is pushed into the solenoid?
2. Which factor is studied when the bar magnet is pushed at different speeds into the solenoid?
3. Which factor is studied when the number of magnets pushed into the solenoid is different?
4. How is the magnitude of induced e.m.f. affected by:
(a) the speed of magnet?
(b) the number of turns of solenoid?
(c) the strength of magnetic field?

The results of Activity 4.11 show that the magnitude
of induced e.m.f. is affected by the speed of relative motion
between the magnet and the conductor, the number of turns of History
the solenoid and the strength of the magnetic field.

For the relative motion • the speed of relative motion
of a straight wire and increases
magnet, the induced • the strength of the magnetic
e.m.f. increases when: field increases
Michael Faraday
(1791-1867)
discovered electromagnetic
induction in the year 1831. He
• the speed of relative motion successfully constructed an
For the relative motion increases electric dynamo. The electric
of a solenoid and • the number of turns of the dynamo was used to generate
magnet, the induced solenoid increases electrical power.
e.m.f. increases when: • the strength of the magnetic
field increases

The magnitude of the e.m.f. increases if more magnetic field lines are cut in a certain period
of time. Faraday's law states that the magnitude of induced e.m.f. is directly proportional to
the rate of cutting of magnetic flux.

LS 4.2.2 155
