Ground Clamps &
Ground Clamps with Hubs

Bare Ground Clamps PC 5560

Bare ground clamps are used to connect bare copper wire to water
pipe, rebar, ground rod or copper water tubing for grounding. Fittings
are UL listed and cast from high strength, highly conductive copper
alloy with steel, brass or bronze screws.

CAT. WIRE RANGE
Features: NO. UPC SOL STR DESCRIPTION PIPE SIZE STD MSTR WT/STD
20B* 10005 8 2 Prsr Cast Brs Plated 1/2 to 1” 25 250 3.83#
• UL Listed
• Pressure 20M 10010 8 2 Prsr Cast Mlbl Finish 1/2 to 1” 25 250 4.40#
Cast or 25 10015 10 2 Bronze 1/2 to 1” 25 250 4.48#
Bronze DB25 67500 10 2 Bronze Direct Burial 1/2 to 1” 25 250 4.79#
• Bonding or DLI25 28090 10 2 Bronze Direct Burial 1/2 to 1” 25 250 4.79#
Grounding Lay in Feature
• With Steel, DB2538 67503 10 2 Bronze Direct Burial 1/2 to 1” 25 250 4.45#
Stainless PL25 56470 10 2 Bronze 1/2 to 1” 25 250 4.85#
Steel, Brass 27 10025 10 2 Bronze 1-1/4 to 2” 5 50 2.18#
or Bronze DB27 67502 10 2 Bronze Direct Burial 1-1/4 to 2” 5 50 2.13#
Screws DLI27 28092 10 2 Bronze Direct Burial 1-1/4 to 2” 5 50 2.13#
Lay in Feature
Fittings & Stampings
1001* 10027 10 2 Bronze 2-1/2 to 4” 5 5.07#
1002* 10028 10 2 Bronze 4-1/2 to-6” 5 9.12#
DB25 and DLI25 Approved For Steel 4/6/8 Rebar
DB2538 Dual Rated Suitable For Pipe or Steel Rebar 3/8 to 1” (#3 - #8). Accommodates Steel Rebar Without Disassembly
* 20B, 1001 & 1002 Non UL Approved

Ground Clamps with Hubs PC 5560

A A B B Ground clamps with hubs are used to connect grounding conductor in
Fittings & Stampings
conduit to water pipe for grounding. Cast from high strength, highly
conductive copper alloy with steel or bronze screws.
WIRE HUB
CAT. NO. UPC PHOTO PIPE SIZE STD MSTR WT/STD
RANGE SIZE
29H 10051 B 10-6 1/2” 1/2 to 1” 25 125 9.80#
29BRZ 10054 B 10-6 1/2” 1/2 to 1” 25 125 10.06#
11.35#
Features: 30H 10053 A 10-2/0 3/4” 1/2 to 1” 25 125 12.33#
25
1/2 to 1”
10056
A
10-3/0
1”
125
31H
• UL Listed 270H 10057 B 10-6 1/2” 1-1/4 to 2” 25 25 14.87#
• Bronze 271H 10059 A 10-2/0 3/4” 1-1/4 to 2” 25 25 16.63#
25
17.44#
25
1-1/4 to 2”
1”
A
10061
272H
10-3/0
• With 1/2”, 3/4” or
1” Hubs 280H 10063 B 10-6 1/2” 2-1/2 to 4” 5 5 6.23#
281H 10064 A 10-2/0 3/4” 2-1/2 to 4” 5 5 6.63#
282H 10066 A 10-3/0 1” 2-1/2 to 4” 5 5 6.64#
All clamps provided with steel screws except 29BRZ (bronze screws)
C20
