Machine Screws

Pan Head Phillips - Stainless PC 4010

Stainless steel pan head machine screws project above the material
surface. This head style is used when clearance is not an important
factor. Length is determined from the base of the fastener head.
Stainless steel resists corrosion and is ideal for applications where
chemical resistance is required.
6-32
CAT. NO. UPC SIZE STD SLV MSTR WT/STD
306 70104 6-32 x 3/8 100 500 4000 0.19# Fasteners & Hardware
306 70106 6-32 x 1/2 100 500 4000 0.22# Features:
306 70108 6-32 x 3/4 100 500 4000 0.30#
306 70110 6-32 x 1 100 500 4000 0.37# ‡ 0DFKLQH 6FUHZV
306 70112 6-32 x 1-1/4 100 500 4000 0.43#
306 70114 6-32 x 1-1/2 100 500 4000 0.51# ‡ 3DQ +HDG
306 70116 6-32 x 2 100 500 3000 0.67# ‡ 3KLOOLSV
8-32 ‡ 6WDLQOHVV 6WHHO
‡ ,QYLQFLER[ TM 8S 7R ´
306 70120 8-32 x 3/8 100 500 4000 0.30#
306 70122 8-32 x 1/2 100 500 4000 0.35#
306 70124 8-32 x 3/4 100 500 4000 0.46#
306 70126 8-32 x 1 100 500 4000 0.56#
306 70128 8-32 x 1-1/4 100 500 4000 0.67#
306 70130 8-32 x 1-1/2 100 500 3000 0.77#
306 70132 8-32 x 2 100 500 3000 1.01#
10-24 Packaging:
306 70140 10-24 x 3/8 100 500 4000 0.41#
306 70142 10-24 x 1/2 100 500 4000 0.49#
306 70144 10-24 x 3/4 100 500 4000 0.62#
306 70146 10-24 x 1 100 500 4000 0.75#
10-32
306 70160 10-32 x 3/8 100 500 4000 0.41#
306 70162 10-32 x 1/2 100 500 4000 0.49# STD SLV
306 70164 10-32 x 3/4 100 500 4000 0.62#
306 70168 10-32 x 1 100 500 4000 0.75#
1/4-20
306 70180 1/4 x 3/8 100 500 4000 0.84#
306 70182 1/4 x 1/2 100 500 4000 0.97#
306 70184 1/4 x 3/4 100 500 3000 1.19#
306 70186 1/4 x 1 100 500 3000 1.45#
306 70188 1/4 x 1-1/4 100 500 3000 1.69# MSTR
306 70190 1/4 x 1-1/2 50 250 1500 0.99#
306 70192 1/4 x 2 50 250 1500 1.21#
Round Head Slotted - Solid Brass PC 4270

Brass round head machine screws project above the material surface.
This head style is used when clearance is not an important factor.
Length is determined from the base of the fastener head. Brass has
good corrosion and rust resistance, especially in salt water and salt
air. It is non magnetic.
6-32
CAT. NO. UPC SIZE STD SLV MSTR WT/STD
50% 55500 6-32 x 1/2 100 500 4000 0.22# Features:
50% 55502 6-32 x 3/4 100 500 4000 0.30#
50% 55504 6-32 x 1 100 500 4000 0.37# ‡ 0DFKLQH 6FUHZV
50% 55506 6-32 x 1-1/4 100 500 4000 0.43# ‡ 5RXQG +HDG
50% 55508 6-32 x 1-1/2 100 500 4000 0.51#
50% 55510 6-32 x 2 100 500 3000 0.67# ‡ 6ORWWHG
8-32 ‡ 6ROLG %UDVV TM 8S 7R ´
‡ ,QYLQFLER[
50% 55550 8-32 x 1/2 100 500 4000 0.35#
50% 55552 8-32 x 3/4 100 500 4000 0.46#
50% 55554 8-32 x 1 100 500 4000 0.56#
50% 55556 8-32 x 1-1/4 100 500 4000 0.67#
50% 55558 8-32 x 1-1/2 100 500 3000 0.77#
50% 55560 8-32 x 2 100 500 3000 1.01#
1/4-20
50% 55700 1/4 x 1/2 100 500 4000 0.97#
50% 55702 1/4 x 3/4 100 500 3000 1.19#
50% 55704 1/4 x 1 100 500 3000 1.45#
50% 55706 1/4 x 1-1/4 100 500 3000 1.69#
50% 55708 1/4 x 1-1/2 50 250 1500 0.99#
50% 55710 1/4 x 2 50 250 1500 1.21#
* RMB10-24 and 10-32 available upon request.
