Page 132 - PONPE Catalogs 2022

PROTRONICS CO.,LTD.
123 Measuring Instruments Store
Line: @ponpe / Facebook: »¹à» / Tel: 02-5316293,5-6 / Website: www.ponpe.com

MO50 MO57 MO230

Specifications Specifications Specifications
Sensor Type : Contact Pins Temperature: -10 ~ 60°C(14 ~ 140°F) Measurement Depth: <4" (100mm)
Wood Moisture Range : 5 to 50% Accuracy: ±1.0°C(±1.8°F) Wood Moisture Range: 0.1 to 99.9%
Other Building Materials : 1.5 to 33% Resolution: 0.1( °C/°F ) Other Building Materials: 0.1 to 99.9%
Resolution : 0.1% Humidity: 10% ~ 99% Resolution: 0.1%
Wood Levels : Low: 5% to 11.9%; Accuracy: ±5.0%RH Wood Moisture Icon Levels: Low: 0.1 to 16.9%;
Medium: 12% to 15.9%; Resolution: 0.1( °C/°F ) Medium: 17.0 to 39.9%;
High: 16 to 50% Size: 108 x 101 x 24mm High: 40.0 to 99.9%
Ordering Weight: 160g Building Material Icon Levels: Low: 0.1 to 16.9%;
MO50 MO55 Medium: 17.0 to 39.9%;
High: 40.0 to 99.9%
Dimensions/Weight: 8.3x2.8x1.3" / 5.5oz
MO265 MO270 ETI 224-070

Specifications Specifications Specifications
Range: 0 to 99.9 (relative) Pinless Range/Depth: 0 to 99.9 Scale 1 - Wood 1 (W1): 6.0 to 40.0 %
Max Resolution: 0.1 Pin Range: 6.0 to 99.9% Scale 2 - Wood 2 (W2): 8.0 to 40.0 %
Dimensions: 8x2.3x1.7" (203x58.4x43.2mm) Transmission Frequency: 2.4GHz Scale 3 - Plaster (P1): 0.1 to 15.0 %
Weight: 7.2oz (204g) Transmission Range: 65ft (20m) Scale 4 - Concrete (C1): 0.5 to 12.0 %
Dimensions: 8x2.3x1.7" (203x58.4x43.2mm) Scale 5 - Linear or Reference (Lin): 0 to 1000
Weight: 7.2oz (204g) Operating temperature: -20ºC to 50ºC
Visual and audible High/Low alarm modes Operating humidity: less than 80%Rh
Pinless measurement depth to 0.75"

38/40-41 ËÁÙ‹·Õè 3 ¶¹¹ÅÓÅÙ¡¡Ò µÓºÅ¤Ù¤µ
ÍÓàÀÍÅÓÅÙ¡¡Ò ¨Ñ§ËÇÑ´»·ØÁ¸Ò¹Õ 12130 เครื่องวัดความชื้นวัสดุ
