Page 159 - PONPE Catalogs 2022
P. 159
PROTRONICS CO.,LTD.
150 Measuring Instruments Store
Line: @ponpe / Facebook: »¹à» / Tel: 02-5316293,5-6 / Website: www.ponpe.com
RC-5 RC-51H RC-1+
Specifications Specifications Specifications
Temperature range: -30 °C~ 70 °C Temp. measuring range: -30°C~70°C Temperature Range: -40°C ~ +70°C
Accuracy: ±0.5 °C Humidity measuring range: 10%~95%RH Accuracy: +-1°C
Resolution: 0.1 °C Resolution: 0.1°C; 0.1%RH Resolution: 0.1°C
Record capacity: 32000 points (MAX) Temp. accuracy: ±0.5°C/0.9°C±1°C/1.8°C(others); Record interval: 10S ~ 16Minutes adjustable
Item Size: approx. 80 (L) x 34 (W) x 14 (H) mm Humidity accuracy: ±3%RH,±5%RH(others) Record capacity: 8000 points
Item Weight: approx. 30 g Dimension: 131mm*24mm Size: 72 x 45 x 12mm
RCW-800 RC-5+ GSP-6
Specifications Specifications Specifications
Temp. measuring range: -40°C~80°C Temp.range: -30°C~+70°C Temp. measuring range: -40 °C ~85 °C
Temp. display resolution: 0.1°C Resolution: 0.1°C Temp. accuracy: ±0.5°C -20 °C ~40 °C ±1 (other)
Tempe. accuracy: ±0.5°(-20°C-40°C); ±1°C(others) Accuracy: ±0.5 °C(-20°C~+40°C); others, ±1°C Humidity range: 10 %~99 %
Temperature sensor type: NTC Communication interface: USB Humidity accuracy: ±3 % RH ±5% RHʢotherʣ
Humidity measuring range: 0%RH-95%RH Power supply: CR2032 replaceable battery Resolution: temperature 0.1
Humidity display resolution: 0.1%RH Dimensions: 80mmx25mmx12mm(LxWxH) Working temperature: -30 °C~70 °C
38/40-41 ËÁÙ‹·Õè 3 ¶¹¹ÅÓÅÙ¡¡Ò µÓºÅ¤Ù¤µ
ÍÓàÀÍÅÓÅÙ¡¡Ò ¨Ñ§ËÇÑ´»·ØÁ¸Ò¹Õ 12130 เครื่องวัดและบันทึกข�อมูล
