 น้ำยาเก็บรักษาหัววัด  Impeller Pump                    ป��มน้ำ



            1100GPH



















          Specifications
          Voltage: 24V
          Current: 1.5 A
          Wattage: 43 watts
          GPH: 1100GPH
          Max Temper.: 110°F (43°C)
          Maximum pumping capacity: 4,000 liters / hour or 35 liters / minute
         The size of the output pipe: 29 mm
         Water pump maximum transmission: 4 meters
         Power cord length: 90 cm
         Structure: Impeller Pump
         Pump body: Thermoplastic




         Dosing Pump                                    ป��มจ�ายสารละลาย





           PP0806A Series

















         Specifications
         Model                     PP0806AA11                   PP0806AB11                    PP0806AD11
         Pressure                      8                            8                            8
         Flow rate                     6                            6                            6
         Speed (strokes / Min)        180                          180                           180
         Connection Size (inch)      3/8”*1/4”                    3/8”*1/4”                    3/8”*1/4”
         Meterial                      PP                           PP                           PP
         Control                Basic Control Model   Basic Control Model + Remote start-stop  100%+50%+4-20mA signal
