P. 404
PQx® SFI-RATED BILLET STEEL
FLYWHEELS
PRW flywheels are CAD engineered, and precision
PQx® XTREME DUTY PLATINUM CNC machined from 1045 billet steel.
SFI-RATED FLEXPLATES PART NO. APPLICATION BALANCE TEETH WEIGHT
Engineered to handle extreme performance applica-
tions and designed to take the punishment of today’s 1626500 Chevy 265-427 1955-85, Circle Track Spec Internal 153 18 lbs
high horsepower engines. Exceeds SFI 29.1 specs. 1628300 Chevy 265-427 V6/V8 1955-85 Internal 168 21.4 lbs
1630580 Chevy 305-350 1986-92, 1-Piece Rear Seal Internal 153 29 lbs
BOLT 1630581 Chevy 305-350 1986-92, 1-Piece Rear Seal External 153 29.3 lbs
PART NO. APPLICATION BALANCE TEETH CIRCLE Chevy 327-427 1963-85 (Except 400) & 572
HIGH INERTIA 1632780 GM Crate Motor Internal 153 29 lbs
Chevy SB/BB, Includes 2001-07 8.1L BB, Chevy 265-427 1955-85 (Except 400) & 572
1835021 Internal 168 6, 8, 9 1635080 Internal 168 30 lbs
2-Piece Rear Seal GM Crate Motor
1845420 Chevy 454 1970-90, 2-Piece Rear Seal External 168 6, 7, 8 1640071 Chevy 383-400 1970-85 External 153 29 lbs
GM LS Series, LS1, LS2, LS3, LS6 1997-Up 6, 9, 10, 1640081 Chevy 383-400 1970-85 External 168 30 lbs
1834620 Internal 168
**Will Fit Turbo 350 & 400 Trans. w/ Adapter 12 1645471 Chevy 454 1970-90, 2-Piece Rear Seal External 153 29 lbs
GM LS Series, LS1, LS2, LS3, LS6 1997-Up 6, 9, 10, 1645481 Chevy 454 1970-90, 2-Piece Rear Seal External 168 31 lbs
1834624 **Will Fit Specialty 6-Bolt Turbo 350 & 400 Internal 168 12 1645482 Chevy 454 1970-90, 1-Piece Rear Seal External 168 31 lbs
Converters w/ Adapter
26.3 lbs
1828110 Ford 4.6L DOHC 1992-06, 8-Bolt Crank Internal 164 1, 2, 6, 7 1628100 Ford 4.6L 1996-04 SOHC-DOHC, 6-Bolt Internal 164 26.55 lbs
Ford 4.6L 1992-08 Modular V8, 8-Bolt
164
Internal
1628180
1830210 Ford 289-351W 1963-95, Eagle Crank Internal 164 1, 2, 6, 7 1628980 Ford 260-302 1964-95 Internal 157 23.4 lbs
1830211 Ford 289-351W 1963-82, 28 oz. External 164 1, 2, 6, 7 1628981 Ford 260-289 1964-69, 28 in-oz External 157 23.95 lbs
1830212 Ford 302 1982-95, 50 oz. External 164 1, 2, 6, 7 1628982 Ford 302 5.0L 1980-95, 50 in-oz External 157 24.1 lbs
Ford 289-351W 1963-95, Eagle Crank,
1830213 Internal 157 2, 6 1630280 Ford 289-302-351 1963-95 Internal 164 30.2 lbs
Small Bell
1830214 Ford 289-351W 1963-82, 28 oz. External 157 2, 6 1630281 Ford 302 5.0L 1980-95, 50 in-oz External 164 30.45 lbs
1830215 Ford 302 1982-95, 50 oz. External 157 2, 6 1642780 Ford FE 332-427 1963-74 Internal 184 33 lbs
1846010 Ford 429-460 1966-97 External 164 1, 6, 7 1645570 Pontiac 326-455 1964-84, Removable 2.50” External 166 30.4 lbs
Crankshaft Pilot Ring & Counterweight
1846011 Ford 429-460, Eagle Crank Internal 164 1, 6, 7
1845502 Pontiac 326-455 1957-79 External 166 6, 7
1845503 Pontiac 326-455 1957-79 Neutral 166 6, 7 PQx® SFI-RATED BILLET
ALUMINUM FLYWHEELS
FORD & GM CRANK Manufactured from the highest quality 6061-T6
SLEEVE ADAPTERS billet aluminum. Feature excellent heat dissipation
and weight reduction.
PART NO. APPLICATION PART NO. APPLICATION BALANCE TEETH WEIGHT
1800302 Ford, For Use w/ PQx Series SBF to GM Transmission 1935000 Chevy BB 454 1970-90, w/ Remov. Cntrwght Extenal 168 14 lbs
1800460 Ford, For Use w/ PQx Series BBF to GM Transmission 1934600 GM 1997-Up LS1/LS2 Internal 168 11.65 lbs
1800346 GM LS, Adapter for Older GM Converter to LS Engine 1928100 Ford 4.6L 1992-08 Modular V8, 12 lbs, 6-Bolt Internal 164 12.25 lbs
• Threaded body shock
• Lightweight billet aluminum body
• Ride height adjustable
• Accepts 2-1/2” I.D. springs
PROMA STAR® CUSTOM MOUNT SHOCKS • Made in the USA
DOUBLE ADJ. SINGLE ADJ. COMPRESSED EXTENDED RECOMMENDED SPRING
PART NO. PART NO. MOUNTING HEIGHT HEIGHT RIDE HEIGHT LENGTH
DD301 DS301 Bearing 8-3/4” 11-1/8” 9-1/2” - 10” 7”
DD401 DS401 Bearing 10-1/8” 14” 11-1/2” - 12-1/2” 9”
DD402 DS402 Poly 10-1/8” 14” 11-1/2” - 12-1/2” 9”
DD403 DS403 Bearing 11-1/8” 15” 12-1/2” - 13-1/4” 10”
DD404 DS404 Poly 11-1/8” 15” 12-1/2” - 13-1/4” 10”
DD501 DS501 Bearing 11-5/8” 16-7/8” 13-1/4” - 14-1/2” 12”
DD502 DS502 Poly 11-5/8” 16-7/8” 13-1/4” - 14-1/2” 12”
DD601 DS601 Bearing 12-5/8” 18-3/4” 15-1/4” - 15-3/4” 14”
DD901 DS901 Bearing 15” 23-5/8” 18-1/2” - 19-1/2” 14”
404
