Gambarajah 8.7: Blok AND get (bersatu)

                       Command: EXPLODE
                       Select objects: Specify opposite corner: 1 found

                   3.  Setelah tiada objek lain yang ingin dilaksanakan arahan ini tekan Enter.












                                     Gambarajah 8.8: Setelah EXPLODE entiti-entiti terpisah


                       Command: EXPLODE
                       Select objects: Specify opposite corner: 1 found
                       Select objects:

                   4.  Proses EXPLODE selesai, objek ini doleh disunting mana bahagian yang berkenaan.
