SELECTION GUIDE SOLID CARBIDE & HSS ALU-POWER END MILLS

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
INCH
E5253 CARBIDE, 2 FLUTE 42° HELIX REGULAR LENGTH ◆ D1/4 D1 1052 ◎
- “BANSHEE” (FLAT SHANK)
E5254 CARBIDE, 2 FLUTE 42° HELIX REGULAR LENGTH ◆ D1/16 D1 1053 ◎
- “BANSHEE” (PLAIN SHANK)

E5976 CARBIDE, 2 FLUTE 37° HELIX with EXTENDED NECK ◆ D1/4 D1 1054 ◎

E5980 CARBIDE, 3 FLUTE 45° HELIX STUB LENGTH ◆ D1/8 D1 1055 ◎

E5981 CARBIDE, 3 FLUTE 45° HELIX REGULAR LENGTH ◆ D1/8 D1 1056 ◎

E5983 CARBIDE, 3 FLUTE, 45° HELIX REGULAR LENGTH ◆ D1/2 D1 1056 ◎
CORNER RADIUS

E5982 CARBIDE, 3 FLUTE 45° HELIX LONG LENGTH ◆ D1/4 D1 1057 ◎

E5984 CARBIDE, 3 FLUTE 45° HELIX LONG LENGTH CORNER RADIUS ◆ D1/2 D1 1057 ◎

E5E44 CARBIDE, 3 FLUTE ROUGHING ◆ D1/4 D1 1058 ◎

E5E98 CARBIDE, 3 FLUTE ROUGHING with NECK ◆ D1/4 D1 1058 ◎

E5E45 CARBIDE, 3 FLUTE 37° ROUGHING BALL NOSE ◆ D1/4 D1 1059 ◎

E5977 CARBIDE, 3 FLUTE 37° HELIX with EXTENDED NECK ◆ D1/4 D1 1060 ◎

E5985 CARBIDE, 3 FLUTE 37° HELIX with EXTENDED NECK ◆ D1/2 D1 1061 ◎
CORNER RADIUS

E5973 CARBIDE, 2 FLUTE CORNER RADIUS with NECK ◆ D5/32 D3/4 1062 ◎

E5974 CARBIDE, 2 FLUTE 50° HELIX STUB CUT LENGTH ◆ R1/8 R3/8 1063 ◎
BALL NOSE with NECK

E5978 CARBIDE, 2 FLUTE 37° HELIX LONG REACH BALL NOSE ◆ R1/8 R1/2 1064 ◎

E5975 CARBIDE, 3 FLUTE 40° HELIX LONG LENGTH ◆ R3/64 R5/16 1065 ◎
BALL NOSE with NECK
◆ U.S.A Stock
