SELECTION GUIDE STANDARD CARBIDE END MILLS

◎ : Excellent ◯ : Good
P H M K N S
SIZE Carbon Alloy Prehardened High High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Hardened Steels Hardened Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Steels Iron Alloy
INCH

UGMF90 CARBIDE, 2 FLUTE REGULAR LENGTH D1/8 D1 1124 ◎ ◎ ◎ ○ ○ ○ ○

E5020 CARBIDE, 2 FLUTE REGULAR LENGTH D1/32 D1 1125 ◎ ◎ ◎ ○ ○ ○ ○

UGMF89 CARBIDE, 4 FLUTE REGULAR LENGTH D1/16 D1 1126 ◎ ◎ ◎ ○ ○ ○ ○

E5021 CARBIDE, 4 FLUTE REGULAR LENGTH D1/16 D1 1127 ◎ ◎ ◎ ○ ○ ○ ○

E5244 CARBIDE, 2 FLUTE STUB LENGTH D1/16 D3/4 1128 ◎ ◎ ◎ ○ ○ ○ ○

UGMGF57 CARBIDE, 4 FLUTE STUB LENGTH D1/16 D3/4 1129 ◎ ◎ ◎ ○ ○ ○ ○

E5245 CARBIDE, 4 FLUTE STUB LENGTH D1/16 D3/4 1130 ◎ ◎ ◎ ○ ○ ○ ○

E5011 CARBIDE, 2 FLUTE LONG LENGTH D1/8 D1 1131 ◎ ◎ ◎ ○ ○ ○ ○

E5012 CARBIDE, 4 FLUTE LONG LENGTH D1/8 D1 1131 ◎ ◎ ◎ ○ ○ ○ ○

UGMGF58 CARBIDE, 4 FLUTE LONG LENGTH D1/8 D1 1132 ◎ ◎ ◎ ○ ○ ○ ○

E5026 CARBIDE, 2 FLUTE EXTRA LONG LENGTH D1/8 D1 1133 ◎ ◎ ◎ ○ ○ ○ ○

UGMGF59 CARBIDE, 4 FLUTE EXTRA LONG LENGTH D1/8 D1 1134 ◎ ◎ ◎ ○ ○ ○ ○

E5065 CARBIDE, 4 FLUTE EXTRA LONG LENGTH D1/8 D1 1135 ◎ ◎ ◎ ○ ○ ○ ○

E5022 CARBIDE, 2 FLUTE STUB LENGTH DOUBLE D1/32 D1/2 1136 ◎ ◎ ◎ ○ ○ ○ ○

E5023 CARBIDE, 4 FLUTE STUB LENGTH DOUBLE D1/16 D1/2 1137 ◎ ◎ ◎ ○ ○ ○ ○

E5025 CARBIDE, 2 FLUTE REGULAR LENGTH DOUBLE D1/8 D1/2 1138 ◎ ◎ ◎ ○ ○ ○ ○

E5024 CARBIDE, 4 FLUTE REGULAR LENGTH DOUBLE D1/8 D1/2 1138 ◎ ◎ ◎ ○ ○ ○ ○

E5249 CARBIDE, 2 FLUTE REGULAR LENGTH BALL NOSE R1/16 R1/2 1139 ◎ ◎ ◎ ○ ○ ○ ○

E5250 CARBIDE, 4 FLUTE REGULAR LENGTH BALL NOSE R1/16 R1/2 1139 ◎ ◎ ◎ ○ ○ ○ ○

UGMF91 CARBIDE, 4 FLUTE REGULAR LENGTH BALL NOSE R1/16 R1/2 1140 ◎ ◎ ◎ ○ ○ ○ ○

E5014 CARBIDE, 2 FLUTE LONG LENGTH BALL NOSE R1/16 R1/2 1141 ◎ ◎ ◎ ○ ○ ○ ○
