Page 1142 - YG 2019

CARBIDE E5251 SERIES PLAIN SHANK CARBIDE
END MILLS E5252 SERIES PLAIN SHANK END MILLS E5216 SERIES PLAIN SHANK

CARBIDE, 2&4 FLUTE STUB LENGTH DOUBLE BALL NOSE CARBIDE, 4 FLUTE REGULAR LENGTH CORNER RADIUS

▶ Same construction features as single end mill in a more economical version. ▶ Suitable for cutting hardened & high alloy steels, steel casting, chill casting, malleable cast iron, CrNi-steels, brass, copper, aluminum with a
▶ Suitable for cutting hardened & high alloy steels, steel casting, chill casting, malleable cast iron, CrNi-steels, brass, copper, aluminum with a high percentage of silicon and abrasive plastics.
high percentage of silicon and abrasive plastics.

R R
↙ ↙

P.1167, 1168 P.1166
E5251 Series ■ 2 FLUTE Unit : Inch Unit : Inch
EDP No. Radius of EDP No. Corner Radius Mill Shank Length Overall
Shank
Mill
Ball Nose Diameter Diameter Length Overall UNCOATED YG:TYLON F R Diameter Diameter of Cut Length
Length
of Cut
UNCOATED TiN COATED TiCN COATED YG:TYLON F YG:TYLON E R (±.0008) 07558-015R 07558TF-015R R.015 1/8 1/8 1/2 1-1/2
47570 47570TN 47570TC 47570TF 47570TE R7/64 7/32 1/4 1/2 2-1/2 07558-030R 07558TF-030R R.030 1/8 1/8 1/2 1-1/2
47573 47573TN 47573TC 47573TF 47573TE R1/8 1/4 1/4 1/2 2-1/2 07565-015R 07565TF-015R R.015 3/16 3/16 5/8 2
47579 47579TN 47579TC 47579TF 47579TE R5/32 5/16 5/16 1/2 2-1/2 07565-030R 07565TF-030R R.030 3/16 3/16 5/8 2
47584 47584TN 47584TC 47584TF 47584TE R3/16 3/8 3/8 9/16 2-1/2 07573-015R 07573TF-015R R.015 1/4 1/4 3/4 2-1/2
47588 47588TN 47588TC 47588TF 47588TE R7/32 7/16 7/16 9/16 2-3/4 07573-030R 07573TF-030R R.030 1/4 1/4 3/4 2-1/2
47593 47593TN 47593TC 47593TF 47593TE R1/4 1/2 1/2 5/8 3 07573-045R 07573TF-045R R.045 1/4 1/4 3/4 2-1/2
07579-015R 07579TF-015R R.015 5/16 5/16 13/16 2-1/2
E5252 Series ■ 4 FLUTE Unit : Inch 07579-030R 07579TF-030R R.030 5/16 5/16 13/16 2-1/2
EDP No. Radius of 07579-045R 07579TF-045R R.045 5/16 5/16 13/16 2-1/2
Shank
Mill
Ball Nose Diameter Diameter Length Overall 07584-015R 07584TF-015R R.015 3/8 3/8 1 2-1/2
Length
of Cut
UNCOATED TiN COATED TiCN COATED YG:TYLON F YG:TYLON E R (±.0008) 07584-030R 07584TF-030R R.030 3/8 3/8 1 2-1/2
48570 48570TN 48570TC 48570TF 48570TE R7/64 7/32 1/4 1/2 2-1/2 07584-045R 07584TF-045R R.045 3/8 3/8 1 2-1/2
48573 48573TN 48573TC 48573TF 48573TE R1/8 1/4 1/4 1/2 2-1/2 07584-060R 07584TF-060R R.060 3/8 3/8 1 2-1/2
48579 48579TN 48579TC 48579TF 48579TE R5/32 5/16 5/16 1/2 2-1/2 07588-015R 07588TF-015R R.015 7/16 7/16 1 2-3/4
48584 48584TN 48584TC 48584TF 48584TE R3/16 3/8 3/8 9/16 2-1/2 07588-030R 07588TF-030R R.030 7/16 7/16 1 2-3/4
48588 48588TN 48588TC 48588TF 48588TE R7/32 7/16 7/16 9/16 2-3/4 07588-045R 07588TF-045R R.045 7/16 7/16 1 2-3/4
48593 48593TN 48593TC 48593TF 48593TE R1/4 1/2 1/2 5/8 3 07588-060R 07588TF-060R R.060 7/16 7/16 1 2-3/4
07588-090R 07588TF-090R R.090 7/16 7/16 1 2-3/4
Mill Dia. 07593-015R 07593TF-015R R.015 1/2 1/2 1 3
Tolerance (inch) 07593-030R 07593TF-030R R.030 1/2 1/2 1 3
07593-045R 07593TF-045R R.045 1/2 1/2 1 3
0~-.0012 *＊0~-.0020
07593-060R 07593TF-060R R.060 1/2 1/2 1 3
*＊The shank of end mills is the same diameter as the cutting portion. 07593-090R 07593TF-090R R.090 1/2 1/2 1 3
07593-125R 07593TF-125R R.125 1/2 1/2 1 3
07595-015R 07595TF-015R R.015 5/8 5/8 1-1/4 3-1/2
07595-030R 07595TF-030R R.030 5/8 5/8 1-1/4 3-1/2
07595-045R 07595TF-045R R.045 5/8 5/8 1-1/4 3-1/2
▶ NEXT PAGE
◎ : Excellent ◯ : Good ◎ : Excellent ◯ : Good
P H M K N S P H M K N S
Carbon Alloy Prehardened Hardened Steels High Hardened High Carbon Alloy Prehardened High Hardened High
Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature Steels Steels Steels Hardened Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Steels Iron Alloy
◎ ◎ ◎ ○ ○ ○ ○ ◎ ◎ ◎ ○ ○ ○ ○ ○
