Page 1232 - YG 2019

COBALT & HSS E2051 SERIES 8% COBALT (M42) COBALT & HSS E2031 / E2032 SERIES 8% COBALT (M42)
FLAT SHANK
FLAT SHANK
END MILLS E1051 SERIES HSS (M2) END MILLS E1031 / E1032 SERIES HSS (M2)
FLAT SHANK
FLAT SHANK
HSSCo8 & HSS, 4 FLUTE REGULAR LENGTH DOUBLE HSSCo8 & HSS, 4, 6&8 FLUTE REGULAR LENGTH 3/4˝ SHANK

▶ Series E2051 four flute end mills are the double-end version of E2031 four flute tools and are used for the same type of finishing operation. Two ▶ E2031(3/4″ shank, multi flute, general purpose end mills) are recommended for finishing operations for Bridgeport machines and other similar
tools on one shank saves on sharpening set-up as well as on initial tool costs. Easy to regrind. operations. Easy to regrind.

P.1283, 1288, 1292 P.1283, 1288, 1292
Unit : Inch E2031(8% COBALT) , E1031(HSS) Series ■ 4 FLUTE Unit : Inch
EDP No. Mill Shank Length Overall EDP No. Mill Shank Length Overall
8% COBALT (M42) HSS (M2) Diameter Diameter of Cut Length 8% COBALT (M42) HSS (M2) Diameter Diameter of Cut Length
12321 12071 1/2 1/2 1 4-1/8 04359 04109 3/4 3/4 1-5/8 3-7/8
12330 12080 9/16 5/8 1-3/8 5 04375 04125 13/16 3/4 1-7/8 4-1/8
12337 12087 5/8 5/8 1-3/8 5 04391 04141 7/8 3/4 1-7/8 4-1/8
12350 12100 11/16 3/4 1-5/8 5-5/8 04407 04157 15/16 3/4 1-7/8 4-1/8
12359 12109 3/4 3/4 1-5/8 5-5/8 04422 04172 1 3/4 1-7/8 4-1/8
12377 12127 13/16 7/8 1-7/8 6-1/8 E2032(8% COBALT) , E1032(HSS) Series ■ 6&8 FLUTE Unit : Inch
12394 12144 7/8 7/8 1-7/8 6-1/8
EDP No.
Mill
Shank
12410 12160 15/16 1 1-7/8 6-3/8 8% COBALT (M42) HSS (M2) Diameter Diameter Length Overall No.of
of Cut
Length
Flute
12426 12176 1 1 1-7/8 6-3/8
04432 04182 1-1/8 3/4 2 4-1/4 6
■ The TiN coated, TiCN coated or TiAIN coated is available on your request.
■ Coating Codes for Cobalt 04440 04190 1-1/4 3/4 2 4-1/4 6
Uncoated EDP NO. + CN(TiN), CC(TiCN), CF(TiAIN F), CE(TiAIN E), CH(Hardslick) 04458 04208 1-1/2 3/4 2 4-1/4 6
■ Coating Codes for HSS 04468 04218 1-3/4 3/4 2 4-1/2 6
Uncoated EDP NO. + HN(TiN), HC(TiCN), HF(TiAIN F), HE(TiAIN E), HH(Hardslick) 04476 04226 2 3/4 2 4-1/2 8
▶ Coated Price Shown in Price List. Call for Availability.
■ The TiN coated, TiCN coated or TiAIN coated is available on your request.
Mill Dia. ■ Coating Codes for Cobalt
Tolerance (inch) Uncoated EDP NO. + CN(TiN), CC(TiCN), CF(TiAIN F), CE(TiAIN E), CH(Hardslick)
■ Coating Codes for HSS
0~—.0010 0~—.0020 Uncoated EDP NO. + HN(TiN), HC(TiCN), HF(TiAIN F), HE(TiAIN E), HH(Hardslick)
▶ Coated Price Shown in Price List. Call for Availability.
The shank of end mills is the same diameter as the cutting portion.
Mill Dia.
Tolerance (inch)
0~+.0010 0~+.0015
The shank of end mills is the same diameter as the cutting portion.

◎ : Excellent ◯ : Good
P H M K N S
◎ : Excellent ◯ : Good
Alloy
P H M K N S Series Carbon Steels Prehardened Hardened Steels High Hardened Stainless Cast High
Steels
Steels
Steels
Carbon Alloy Prehardened Hardened Steels High Hardened High Steels Iron Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Alloy
Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70
Iron
Steels
~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy E1031 ◎ ◎ ○ ○ ○
E2031
◎ ◎ ○ ○ ○ E1032 ◎ ◎ ○ ○
E2032
