Page 1355 - YG 2019

ROTARY ROTARY
TOOL HOLDERS TOOL HOLDERS

HIGH BALANCED END MILL HOLDER CAT HIGH BALANCED END MILL HOLDER CAT

d D d D

TAPER No. L TAPER No. L

Taper Coolant Taper Coolant
ASME B5.50 Accuracy G Value RPM System ASME B5.50 Accuracy G Value RPM System
ASME B5.50-2009-CAT - CAT AT3 2.5 25,000 AD ASME B5.50-2009-CAT - CAT AT3 2.5 25,000 AD
STUB Unit : inch EXTENDED Unit : inch
EDP No. TAPER No. MODEL No. d D L EDP No. TAPER No. MODEL No. d D L
AK206B25 CAT40 - EMH 1/2 - 1.75 0.500 1.25 1.75 AK104B25 CAT40 - EMH 3/8 - 4.50 0.375 1.00 4.50
AK208B25 CAT40 - EMH 5/8 - 1.75 0.625 1.50 1.75 AK106B25 CAT40 - EMH 1/2 - 4.63 0.500 1.25 4.63
AK210B25 40 CAT40 - EMH 3/4 - 1.75 0.750 1.75 1.75 AK108B25 CAT40 - EMH 5/8 - 5.75 0.625 1.50 5.75
AK214B25 CAT40 - EMH 1" - 1.75 1.000 1.75 1.75 AK110B25 40 CAT40 - EMH 3/4 - 5.75 0.750 1.75 5.75
AK217B25 CAT40 - EMH 1 1/4 - 2.00 1.250 2.25 2.00 AK112B25 CAT40 - EMH 7/8 - 6.00 0.875 1.88 6.00
AK114B25 CAT40 - EMH 1" - 6.00 1.000 2.00 6.00
STANDARD Unit : inch AK117B25 CAT40 - EMH 1 1/4 - 6.25 1.250 2.50 6.25
EDP No. TAPER No. MODEL No. d D L AK121B25 CAT40 - EMH 1 1/2 - 6.63 1.500 2.50 6.63
AL104B25 CAT50 - EMH 3/8 - 4.50 0.375 1.00 4.50
AK000B25 CAT40 - EMH 1/8 - 2.50 0.125 0.69 2.50 AL106B25 CAT50 - EMH 1/2 - 4.63 0.500 1.25 4.63
AK001B25 CAT40 - EMH 3/16 - 2.50 0.187 0.69 2.50 AL108B25 CAT50 - EMH 5/8 - 5.75 0.625 1.50 5.75
AK002B25 CAT40 - EMH 1/4 - 2.50 0.250 0.78 2.50 AL110B25 CAT50 - EMH 3/4 - 5.75 0.750 1.75 5.75
AK003B25 CAT40 - EMH 5/16 - 2.50 0.312 0.88 2.50 AL112B25 50 CAT50 - EMH 7/8 - 5.75 0.875 1.88 5.75
AK004B25 CAT40 - EMH 3/8 - 2.50 0.375 1.00 2.50 AL114B25 CAT50 - EMH 1" - 6.00 1.000 2.00 6.00
AK005B25 CAT40 - EMH 7/16 - 2.50 0.437 1.13 2.50 AL117B25 CAT50 - EMH 1 1/4 - 6.00 1.250 2.50 6.00
AK006B25 40 CAT40 - EMH 1/2 - 2.63 0.500 1.25 2.63 AL121B25 CAT50 - EMH 1 1/2 - 6.00 1.500 2.50 6.00
AK008B25 CAT40 - EMH 5/8 - 3.75 0.625 1.50 3.75 AL129B25 CAT50 - EMH 2" - 7.63 2.000 3.75 7.63
AK010B25 CAT40 - EMH 3/4 - 3.75 0.750 1.75 3.75
AK012B25 CAT40 - EMH 7/8 - 4.00 0.875 1.88 4.00 * Set screws for End Mill Holders on page 1365.
AK014B25 CAT40 - EMH 1" - 4.00 1.000 2.00 4.00
AK017B25 CAT40 - EMH 1 1/4 - 4.25 1.250 2.50 4.25
AK021B25 CAT40 - EMH 1 1/2 - 4.63 1.500 2.50 4.63
AL002B25 CAT50 - EMH 1/4 - 2.50 0.250 0.78 2.50
AL003B25 CAT50 - EMH 5/16 - 2.50 0.312 0.88 2.50
AL004B25 CAT50 - EMH 3/8 - 2.50 0.375 1.00 2.50
AL005B25 CAT50 - EMH 7/16 - 2.63 0.437 1.13 2.63
AL006B25 CAT50 - EMH 1/2 - 2.63 0.500 1.25 2.63
AL008B25 CAT50 - EMH 5/8 - 3.75 0.625 1.50 3.75
AL010B25 50 CAT50 - EMH 3/4 - 3.75 0.750 1.75 3.75
AL012B25 CAT50 - EMH 7/8 - 3.75 0.875 1.88 3.75
AL014B25 CAT50 - EMH 1" - 4.00 1.000 2.00 4.00
AL017B25 CAT50 - EMH 1 1/4 - 4.00 1.250 2.50 4.00
AL021B25 CAT50 - EMH 1 1/2 - 4.00 1.500 2.50 4.00
AL029B25 CAT50 - EMH 2" - 5.63 2.000 3.75 5.63
* Set screws for End Mill Holders on page 1365.

1356 • phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com • 1357
