COMBO TAPS COMBO TAPS

TK-S / TK-C SERIES TCE-S/TCF-S/TCE-C/TCF-C SERIES

SPIRAL POINT TAPS for Multi-Purpose SPIRAL POINT TAPS for Stainless Steels

DIN Length-ANSI Shank

Thread Depth / Thread Depth /
Hole Type Hole Type
3.0×D 3.0×D

4P~5P Steam Super UNC USCTI 4P Steam
MU HSS-EX M/MF Oxide TiCN VA HSS HSS-EX UNF 302A Oxide TiCN
Unit : Inch Unit : Inch
Overall Thread Shank Square Square EDP No. Overall Thread Shank Square Square EDP No.
SIZE & TPI Limit Length Length Diameter Size Length No. of Steam SIZE & TPI Limit Length Length Diameter Size Length No. of Steam
Flute
Flute
L Lt D K kl Oxide TiCN L Lt D K kl Oxide TiCN
M3 x 0.5 D3 2.20 .374 .141 .110 .188 3 TK203S TK203C #5 - 40 UNC H2 1.94 .374 .141 .110 .188 3 TCE202S TCE202C
M3.5 x 0.6 D4 2.20 .413 .141 .110 .188 3 TK224S TK224C #5 - 40 UNC H3 1.94 .374 .141 .110 .188 3 TCE203S TCE203C
M4 x 0.7 D4 2.48 .453 .168 .131 .250 3 TK244S TK244C #6 - 32 UNC H3 2.00 .413 .141 .110 .188 3 TCE243S TCE243C
M5 x 0.8 D4 2.76 .531 .194 .152 .250 3 TK284S TK284C #8 - 32 UNC H3 2.13 .453 .168 .131 .250 3 TCE283S TCE283C
M6 x 1.0 D5 3.15 .591 .255 .191 .312 3 TK315S TK315C #10 - 24 UNC H3 2.38 .531 .194 .152 .250 3 TCE323S TCE323C
M8 x 1.25 D5 3.54 .669 .318 .238 .375 3 TK365S TK365C #10 - 32 UNF H3 2.38 .531 .194 .152 .250 3 TCE343S TCE343C
M10 x 1.5 D6 3.94 .748 .381 .286 .438 3 TK426S TK426C 1/4 - 20 UNC H3 2.50 .591 .255 .191 .312 3 TCE403S TCE403C
M10 x 1.25 D5 3.94 .748 .381 .286 .438 3 TK435S TK435C 1/4 - 20 UNC H5 2.50 .591 .255 .191 .312 3 TCE405S TCE405C
M12 x 1.75 D6 4.33 .984 .367 .275 .438 3 TK506S TK506C 1/4 - 28 UNF H3 2.50 .591 .255 .191 .312 3 TCE423S TCE423C
M12 x 1.25 D5 3.94 .984 .367 .275 .438 3 TK525S TK525C 5/16 - 18 UNC H3 2.72 .669 .318 .238 .375 3 TCE443S TCE443C
M14 x 2.0 D7 4.33 .984 .429 .322 .500 3 TK547S TK547C 5/16 - 18 UNC H5 2.72 .669 .318 .238 .375 3 TCE445S TCE445C
M14 x 1.5 D6 3.94 .984 .429 .322 .500 3 TK556S TK556C 5/16 - 24 UNF H3 2.72 .669 .318 .238 .375 3 TCE463S TCE463C
M16 x 2.0 D7 4.33 1.083 .480 .360 .562 3 TK607S TK607C 3/8 - 16 UNC H3 2.94 .748 .381 .286 .438 3 TCE483S TCE483C
M16 x 1.5 D6 3.94 1.083 .480 .360 .562 3 TK616S TK616C 3/8 - 16 UNC H5 2.94 .748 .381 .286 .438 3 TCE485S TCE485C
M18 x 2.5 D7 4.92 1.083 .542 .406 .625 3 TK657S TK657C 3/8 - 24 UNF H3 2.94 .748 .381 .286 .438 3 TCE503S TCE503C
M18 x 1.5 D6 4.33 1.083 .542 .406 .625 3 TK676S TK676C 7/16 - 14 UNC H3 3.16 .866 .323 .242 .406 3 TCE523S TCE523C
7/16 - 14 UNC H5 3.16 .866 .323 .242 .406 3 TCE525S TCE525C
▶Steam Oxide is not recommended for Aluminum and Aluminum alloys.
7/16 - 20 UNF H3 3.16 .866 .323 .242 .406 3 TCE543S TCE543C
7/16 - 20 UNF H5 3.16 .866 .323 .242 .406 3 TCE545S TCE545C
1/2 - 13 UNC H3 3.38 .984 .367 .275 .438 3 TCE563S TCE563C
1/2 - 13 UNC H5 3.38 .984 .367 .275 .438 3 TCE565S TCE565C
1/2 - 20 UNF H3 3.38 .984 .367 .275 .438 3 TCE583S TCE583C

▶Super HSS(#5~1/2) and HSS-EX(9/16~1") ▶ NEXT PAGE
